SERIES AH1 FLEXIBLE HOSE FRICTION LOSS
DATA (CCC)
• The following table contains CCC friction loss data. Always refer to the
applicable "Listing and Approval Information – Flexible Hose and Bracket
Combinations" section to verify the listings/approvals for the particular flexible
hose/bracket combination.
Length of
Flexible Hose
Model mm/inches
AH1-31
AH1-36
AH1-48
AH1-60
AH1-72
178-mm/7-inch minimum bend radius.
Friction loss data is in accordance with GB5135.16. Corresponding flow rate is 113.55 liters per
minute/30 gallons per minute.
TECHNICAL DATA FOR FLEXIBLE HOSES REV_A
NOTICE
Straight Configuration
790
31
915
36
1120
48
1525
60
1830
72
Equivalent Length - meters/feet
4.78
15.7
5.59
18.3
9.75
32.0
12.15
39.9
14.26
46.8
Bend Configuration
5.80
19.0
10.15
33.3
16.25
53.3
22.94
75.3
25.98
85.2
