INTRODUCTION

Victaulic VicFlex
® ™
using a flexible hose and fittings and are designed for use in ceiling suspension systems.
• Refer to the "General Information" and "Construction Requirements" sections.
• Refer to the "Technical Data" section.

STYLE AB1 BRACKET ASSEMBLY DRAWING

3
Item
1 24-inch/610-mm or 48-inch/1219-mm Square Bar*
2 Center Gate Assembly with Wing Nut
3 End Bracket with Sheet Metal Screw
4 Wing Screw
5 Relocation Warning Label
6 Helical Spring-Lock Washer
7 T25 Socket Button Head Cap Screw
*For the UL Listing, when the 48-inch/1220-mm length bracket is used, the maximum
sprinkler K-factor is K8.0 and the maximum spacing is 30-inches/762-mm. Square bar
length is in reference to nominal ceiling grid spacing.
I-VICFLEX_22
Sprinkler Fittings connect the sprinkler piping directly to the sprinkler
6
7
5
Style AB1 Description
1
STYLE AB1, AB2, AND AB10 BRACKETS
INSTALLATION INSTRUCTIONS REV_A
2
4
3
