INSTRUCTIONS FOR THE INITIAL USE OF A
VICTAULIC
NO. 102 STRAIGHT TEE INSTALLATION-READY
FITTING WITH A VICTAULIC
HOSE (1-INCH/DN25 IGS
• The following procedure applies only to 1-inch/DN25 No. 101 90° Elbows and
No. 102 Straight Tees (IGS
• No. 101 90° Elbows and No. 102 Straight Tees do not ship preassembled to the
Series AH1-CC, AH1-CC-LP, AH2-CC, AH2-CC-LP or AH2-CC-300 Flexible Hose.
• The No. 101 or No. 102 does not need to be fully disassembled for initial
installation onto the inlet end of the Series AH1-CC, AH1-CC-LP, AH2-CC,
AH2-CC-LP or AH2-CC-300 Flexible Hose.
Inspect
Inlet End
of Flexible Hose
4. Loosen and remove the hardware from the side of the No. 101 90° Elbow or No. 102
Straight Tee that is intended to connect with the inlet of the Series AH1-CC, AH1-CC-LP,
AH2-CC, AH2-CC-LP OR AH2-CC-300 Flexible Hose.
CONNECTION TO THE SPRINKLER PIPING REV_A
FIRELOCK
®
connection).
™
Spacer
NO. 101 90° ELBOW OR
™
VICFLEX
®
CONNECTION)
™
NOTICE
1. Loosen the nut of the Style 108 Coupling.
Remove the Style 108 Coupling from the end
of the Series AH1-CC, AH1-CC-LP, AH2-CC,
AH2-CC-LP or AH2-CC-300 Flexible Hose.
2. Inspect the inlet end of the Series AH1-CC
or AH2-CC Flexible Hose to verify that there is
no damage (dents, crushed edges, etc.).
A new, Victaulic
AH1-CC-LP, AH2-CC, AH2-CC-LP or
AH2-CC-300 Flexible Hose shall be used if any
damage is present.
3. Verify that the spacer is oriented on the inlet
end of the Series AH1-CC, AH1-CC-LP,
AH2-CC, AH2-CC-LP or AH2-CC-300 Flexible
Hose, as shown to the left.
FLEXIBLE
™
-supplied Series AH1-CC,
®
