MAXIMUM AMBIENT TEMPERATURE RATING OF
FLEXIBLE HOSES
Generally, the maximum ambient temperature rating of Victaulic
225°F/107°C.
Exceptions are the following:
• 150° F/ 66° C (UL) with AH2-300 and AH2-CC-300 hose models.
• 150° F/66° C (UL/FM) when the AH2 or AH2-CC Flexible Hose is used for the seal of
the Style AB6 Bracket Assembly.
NOTE: When using the optional silicone seal, the AB6 bracket paired with either the AH2
or AH2-CC Flexible Hose will have a maximum ambient temperature of 225° F/107° C.
Additionally, the optional silicone seal cannot be used with panel configurations that have
corrugation heights greater than 1/8 inch/3.2 mm.
AMBIENT TEMPERATURE FOR WET PIPING
SYSTEMS INSTALLED WITH STYLE VS1 DRY
SPRINKLERS
The following table is used when the ambient temperature is maintained between
40° F/4° C and 60°F/16°C around the wet piping system.
Exposed Minimum Barrel
Ambient
Temperature
Exposed to
Discharge
End of
Sprinkler
°F/°C
40
4
30
-1
20
-7
10
-12
0
-18
-10
-23
-20
-29
-30
-34
-40
-40
-50
-46
-60
-51
NOTE: Exposed minimum barrel lengths are inclusive up to 30-mph/48-kph wind velocities.
TECHNICAL DATA FOR FLEXIBLE HOSES REV_A
Length "Y" inches/mm
40°F 50°F
4°C 10°C
0 0
0 0
0 0
0 0
4 0
100 0
8 1
200 25
12 3
300 75
14 4
350 100
14 6
350 150
16 8
400 200
18 8
450 200
20 10
500 250
20 10
500 250
Face of
Fitting
60°F
16°C
0
0
0
0
0
0
0
0
0
0
1
25
3
75
4
100
Face of
Fitting
4
100
6
150
6
150
VicFlex hoses is
® ™
Y
Heated
Space
Exterior
Sidewall
Unheated
Y
Space
Heated
Space
Exterior
Pendent
I-VICFLEX_159
Unheated
Space
