STYLE C-AQC FLEXIBLE HOSE SPRINKLER
FITTING FRICTION LOSS DATA (CCC)
• The following table contains CCC friction loss data. Always refer to the
applicable "Listing and Approval Information – Flexible Hose and Bracket
Combinations" section to verify the listings/approvals for the particular flexible
hose/bracket combination.
Length of
Flexible
inches/
Model
C-AQC-39
C-AQC-47
C-AQC-59
TECHNICAL DATA FOR FLEXIBLE HOSES REV_A
Hose Outlet Size
inches/
mm Metric
1/2
39
DN15
1000
1/2
47
DN15
1200
1/2
59
DN15
1500
NOTICE
Equivalent Length
of 1-inch/DN25
Schedule 40 Pipe
feet/meters
5.0
1.51
7.9
2.41
17.3
5.26
Maximum
Number
of 90° Bends
1
2
3
I-VICFLEX_199
