SERIES AH2/AH2-CC FLEXIBLE HOSE FRICTION
LOSS DATA (FM)
• The following table contains FM friction loss data. Always refer to the applicable
"Listing and Approval Information – Flexible Hose and Bracket Combinations"
section to verify the listings/approvals for the particular flexible hose/bracket
combination.
Flexible Hose
Model inches/mm
AH2-31
AH2-CC-31
AH2-36
AH2-CC-36
AH2-48
AH2-CC-48
AH2-60
AH2-CC-60
AH2-72
AH2-CC-72
3/4-inch/DN20 outlet data shown with K14.0 - For other K-factor friction loss data, refer to Victaulic
1
submittal 10.85.
7-inch/178-mm minimum bend radius (tested with standard 5 3/4-inch/146-mm length straight
2
reducer).
A higher number of bends may be permitted, provided the sum of degrees is equal to or less than
3
the total maximum allowable degrees of bends. (e.g. Two 90° bends equal 180°. Three 90° bends
equal 270°). The minimum bend radius and maximum number of 90° offset (bends), stated in these
installation instructions, refer to the final installed condition of the hose.
NOTE: Differences in equivalent lengths are due to varying test methods, per the FM 1637 standard.
Refer to this standard for additional information regarding friction loss test methods.
When using a No. 101 90° Elbow or a No. 102 Straight Tee in place of a Style 108 Coupling on the end
of a Series AH2-CC Flexible Hose, the friction loss data shown above shall be added to the No. 101 or
No. 102 friction loss data published in Victaulic
I-VICFLEX_172
Length of
Outlet Size
inches/Metric
31
790
36
915
48
1220
60
1525
72
1830
TECHNICAL DATA FOR FLEXIBLE HOSES REV_A
NOTICE
1-inch/DN25
Schedule 40
1
1/2
DN15
3/4
DN20
1/2
DN15
3/4
DN20
1/2
DN15
3/4
DN20
1/2
DN15
3/4
DN20
1/2
DN15
3/4
DN20
submittal 10.54.
®
Equivalent
Length of
Pipe
2
feet/meters of 90° Bends
13.8
4.2
14.9
4.5
16.6
5.1
19.4
5.9
23.4
7.1
30.3
9.2
30.2
9.2
33.9
10.3
37.0
11.3
37.5
11.4
Maximum
Number
3
2
2
3
4
4
®
