SERIES AH2, AH2-CC, AH2-LP, AND AH2-CC-LP
FLEXIBLE HOSE FRICTION LOSS DATA (VDS)
• The following table contains VdS friction loss data. Always refer to the
applicable "Listing and Approval Information – Flexible Hose and Bracket
Combinations" section to verify the listings/approvals for the particular flexible
hose/bracket combination.
Length of
Flexible Hose
mm/
inches
790
31
915
36
1220
48
1525
60
1830
72
Only VdS Approved pendent spray sprinklers of 10-mm, 15-mm, and 20-mm nominal diameters with
K-factors of 57, 80, and 115 shall be used.
• Tested with a 5 3/4-inch/146-mm length straight reducer.
• When using a No. 101 90° Elbow or a No. 102 Straight Tee in place of a Style 108 Coupling on
the end of a Series AH1-CC or AH2-CC Flexible Hose, the friction loss data shown above shall
be added to the No. 101 or No. 102 friction loss data published in Victaulic
• Flexible Hoses are VdS Approved for use in wet systems only.
NOTE: The VdS Approval applies only for use with specific suspended ceiling systems. Refer to the
"Construction Requirements" section of this handbook.
• Other manufacturers' ceiling systems, with comparable or better performance, can be
considered for approval.
• VdS standards for safety include, but are not limited to: pressure cycling, corrosion resistance,
flow characteristics, vibration resistance, leakage, mechanical strength, and hydrostatic
strength.
• Differences in equivalent lengths are due to varying test methods, per FM 1637 and VdS
standards. Refer to these standards for additional information regarding friction loss test
methods.
I-VICFLEX_192
NOTICE
Series AH2, AH2-CC, AH2-LP and AH2-CC
Equivalent Length of
Outlet
Size
Metric/ EN 10255 DN25
inches
DN15/1/2
DN20/3/4
DN15/1/2
DN20/3/4
DN15/1/2
DN20/3/4
DN15/1/2
DN20/3/4
DN15/1/2
DN20/3/4
TECHNICAL DATA FOR FLEXIBLE HOSES REV_A
Steel Pipe
in meters/feet
According to
(33,7 x 3,25)
10.4
34.1
13.4
44.0
16.2
53.1
19.2
63.0
22.8
74.8
Maximum Number
of 90° Bends at
76.2-mm/3-inch
Bend Radius
3
3
3
4
4
submittal 10.54.
®
