Victaulic VicFlex I-VICFLEX Field Installation Handbook page 19

Style AQC-U
The Victaulic VicFlex
®
cleanroom ceilings. Refer to the "Listing and Approval Information - Flexible Hose
Assemblies with Corresponding Maximum Working Pressure Rating (AQC-U/AQC and
AQD)" section in this handbook.
Style C-AQC (Regional Availability Only)
The Victaulic VicFlex
®
for use with cleanroom ceilings. Refer to the "Listing and Approval Information - Flexible
Hose Assemblies with Corresponding Maximum Working Pressure Rating (AQC-U/C-AQC
and AQD)" section in this handbook.
NOTES FOR STYLE AQC-U AND C-AQC:
Channel Systems is a product of Channel Systems, Inc.
CLIN is a product of Cleanroom Industries Sdn. Bdh.
Gordon is a product of Gordon Incorporated.
M+W Zander Facility Engineering GmbH is a company of the M+W Group.
SBB Daldrop and SBB Gorilla Grid are products of SBB, Inc.
Topwell is a product of Chyi Lee Industry Co., Ltd.
Tenryo is a product of Tenryo Technology & Engineering Co., Ltd.
Topline is a product of Topline System Engineering Co., Ltd.
Style AQD
The Victaulic VicFlex
®
fiberglass reinforced pipe (FRP) ducts.
Style AQD-M
The Victaulic VicFlex
®
square metal ducts.
Style VB1 Bracket for Style VS1 Dry Sprinklers
The Victaulic VicFlex
®
Style VB2 Bracket for Style VS1 Dry Sprinklers
The Victaulic VicFlex
®
suspended ceilings only.
Style VB3 and VB4 Brackets for Style VS1 Dry Sprinklers
Construction shall meet the requirements of ASTM C635 for ceiling suspension systems
installed with lay-in tiles (in accordance with ASTM C636 standards). In addition, the
Style VB3 and VB4 Brackets are designed for use on wood joists/studs and on ASTM
C645 metal joists/studs installed in accordance with ASTM C754 standards.
CONSTRUCTION REQUIREMENTS REV_A
Style AQC-U Sprinkler Fitting is FM Approved for use with
™
Style C-AQC Sprinkler Fitting is FM Approved and CCC Approved
™
Style AQD Sprinkler Fitting is designed for use on round or square
™
Style AQD-M Sprinkler Fitting is designed for use on round or
™
Style VB1 Bracket is designed for use on wood or metal joists.
™
Style VB2 Bracket is designed for use with ASTM C635
™
I-VICFLEX_19
