SERIES AH2-AB6/AH2-CC-AB6 FRICTION LOSS
DATA (FM)
• The following table contains FM friction loss data. Always refer to the applicable
"Listing and Approval Information – Flexible Hose and Bracket Combinations"
section to verify the listings/approvals for the particular flexible hose/bracket
combination.
Flexible Hose
Model
AH2-31-AB6
AH2-CC-31-
AB6
AH2-36-AB6
AH2-CC-36-
AB6
AH2-48-AB6
AH2-CC-48-
AB6
AH2-60-AB6
AH2-CC-60-
AB6
AH2-72-AB6
AH2-CC-72-
AB6
TECHNICAL DATA FOR FLEXIBLE HOSES REV_A
Length of
Sprinkler
inches/mm
31
790
36
915
48
1220
60
1525
72
1830
NOTICE
Equivalent Length
of 1-inch/DN25
Schedule 40 Pipe
K-factor
K5.6
K8.0
K5.6
K8.0
K5.6
K8.0
K5.6
K8.0
K5.6
K8.0
feet/meters
13.8
4.2
20.7
6.3
16.6
5.1
25.0
7.6
23.4
7.1
35.5
10.8
30.2
9.2
39.6
12.1
37.0
11.3
43.5
13.3
I-VICFLEX_175
Maximum
Number
of 90°
Bends
2
2
3
4
4
