• Visual inspection of each joint is required.
• Improperly assembled joints shall be corrected before the system is tested or
placed into service.
• Any components that exhibit physical damage due to improper assembly shall be
replaced before the system is tested or placed into service.
Failure to follow these instructions could cause joint failure, resulting in death or
serious personal injury and property damage.
GOOD
6. Visually inspect the bolt pads at each joint to verify that metal-to-metal contact is
achieved, in accordance with step 5 on the previous page.
• Refer to pages 137 – 138 for flexible hose reassembly instructions.
