ATTACHING THE STYLE AQC-U TO THE
CLEANROOM CEILING GRID (GORDON
INSTALLATION)
VicFlex Series AH2-CC
Flexible Sprinkler Hose
4 x ¼-20 Screw*
Sprinkler with Bulb
Protector*
• If the sprinkler deflector or bulb protector appears too large to pass through the
ceiling grid, it may be necessary to install the sprinkler after the Style AQC-U is
tightened to the ceiling grid.
I-VICFLEX_90
Installation Components
Gordon/VicFlex
Sprinkler Assembly
Bracket
Gasket
Ceiling Grid*
* Components provided by ceiling grid
manufacturer or others.
NOTICE
Exploded View of
STYLE AQC-U BRACKET INSTALLATION
FOR CLEANROOM APPLICATIONS REV_A
