SERIES AH1/AH1-CC FLEXIBLE HOSE FRICTION
LOSS DATA (FM)
• The following table contains FM friction loss data. Always refer to the applicable
"Listing and Approval Information – Flexible Hose and Bracket Combinations"
section to verify the listings/approvals for the particular flexible hose/bracket
combination.
Model
AH1-31
AH1-CC-31
AH1-36
AH1-CC-36
AH1-48
AH1-CC-48
AH1-60
AH1-CC-60
AH1-72
AH1-CC-72
3/4-inch/DN20 outlet data shown with K14.0 - For other K-factor friction loss data, refer to Victaulic
1
submittal 10.95.
7-inch/178-mm minimum bend radius (tested with standard 5 3/4-inch/146-mm length straight
2
reducer).
A higher number of bends may be permitted, provided the sum of degrees is equal to or less than
3
the total maximum allowable degrees of bends (e.g. Two 90° bends equal 180°. Three 90° bends
equal 270°). The minimum bend radius and maximum number of 90° offset (bends), stated in these
installation instructions, refer to the final installed condition of the hose.
• For friction loss data for elbows, refer to Victaulic
• When using a No. 101 90° Elbow or a No. 102 Straight Tee in place of a Style 108 Coupling on
the end of a Series AH1-CC Flexible Hose, the friction loss data shown above shall be added to
the No. 101 or No. 102 friction loss data published in Victaulic
NOTE: Differences in equivalent lengths are due to varying test methods, per FM 1637 standards.
Refer to these standards for additional information regarding friction loss test methods.
I-VICFLEX_170
Length of
Flexible
Hose
inches/ Outlet Size
mm inches
31
790
36
915
48
1220
60
1525
72
1830
TECHNICAL DATA FOR FLEXIBLE HOSES REV_A
NOTICE
Equivalent
Length of
1-inch/33.7-mm
Schedule 40
Pipe
1
meters
35.7
1/2
10.9
32.9
3/4
10.0
42.1
1/2
12.8
39.2
3/4
11.9
57.5
1/2
17.5
54.4
3/4
16.6
72.9
1/2
22.2
69.5
3/4
21.18
88.4
1/2
26.9
84.7
3/4
25.8
submittal 10.95.
®
feet/ Maximum Number
2
of 90° Bends
submittal 10.54.
®
3
2
2
3
4
4
®
