Speaker
Before removing the speaker, perform the following steps:
D
Open the system unit
D
Remove the CPU assembly
D
Disconnect the speaker cable from the CPU board
Push in the speaker retainer clips and lift out the speaker, as shown in Figure 5–30.
Figure 5–30. Removing the Speaker
Push in the Speaker
Retainer Clips
Field Replaceable Units
5–35
