Configuration
This chapter provides details about setting up and changing the system configuration.

Workstation Configurations

Refer to the HP 9000 Series 700 Configuration Guide for a complete list of sup-
ported accessories, peripherals, and operating systems for this workstation.

FRU Configurations

This section provides information for setting up or changing the configuration of the
system Field Replaceable Units (FRUs).

Internal Storage Configurations

Table 3–1 lists the recommended SCSI IDs for internal storage devices. Figures 3–1,
3–2 and 3–3 show the Fast,Wide Differential SCSI ID settings for the hard disk
drives. Figure 3–4 shows the Ultra Wide Single–Ended SCSI ID settings for the hard
disk drives. Figure 3–5 show the Narrow Single-Ended SCSI ID settings for the CD-
ROM drive and the DDS drive. Figure 3–6 shows the Operation Mode switches for
the DDS drive. Figure 3–7 shows the Narrow Single-Ended SCSI ID settings for the
floppy drive, and Figure 3–8 shows the floppy drive terminator location.
NOTICE: There must ALWAYS be a terminator at both ends of
a SCSI bus. This means one internal terminator and
one external terminator.
These SCSI IDs are the recommended IDs for each storage device. If an existing
device already uses an ID, select an alternate ID.
Table 3-1. Default SCSI IDs
FWD or UWSE SCSI
1st Hard Disk Drive
2nd Hard Disk Drive
Narrow Single-Ended SCSI
CD-ROM Drive
DDS Drive
Floppy Drive
ID6
ID5
ID2
ID3
ID0
