HP Visualize J2240 Service Handbook page 67

FRU Ostat
Selftest CPU 0 FLT
TEST
Selftest CPU 0 FLT
TEST
Selftest CPU 0 FLT
TEST
Selftest CPU 0 FLT
WARN
TEST
Selftest CPU 0 FLT
Selftest Mem Sys FLT
Selftest CPU 0 FLT
Selftest CPU 0 FLT
Selftest Mem Sys FLT
Selftest Mem Sys FLT
Selftest Mem Sys FLT
Selftest Mem Sys FLT
Selftest Mem Sys FLT
Selftest Mem Sys FLT
Selftest Mem Sys FLT
Selftest Mem Sys FLT
HPMC Occurred! FLT
Selftest Mem Sys FLT
Selftest Mem Sys FLT
Selftest Mem Sys FLT
Selftest Mem Sys FLT
Selftest Mem Sys FLT
Selftest Mem Sys FLT
Selftest Mem Sys FLT
4–16 Troubleshooting
Table 4–1. I/O Failure Codes (Cont.)
Code Name
4030 CHASSIS_CACHE_PM_FLUSH_
ERR
4040 CHASSIS_CACHE_FLUSH
4040 CHASSIS_CACHE_FLUSH_ERR
4050 CHASSIS_ICACHE_MISS
4051 CHASSIS_ICACHE_MISS_ERR
4060 CHASSIS_DCACHE_MISS
4060 CHASSIS_DCACHE_MISS_ERR
4060 CHASSIS_DCACHE_MISS_
WARN
4070 CHASSIS_DUAL_ISSUE
4071 CHASSIS_DUAL_ISSUE_
ERROR
7000 CHASSIS_MEM_HPMC_ERR
7001 CHASSIS_ ICACHE_PARITY_
ERROR
7002 CHASSIS_DCACHE_PARITY_
ERROR
7003 CHASSIS_MSI_READ_ERROR
7004 CHASSIS_MSI_WRITE_ERROR
7005 CHASSIS_RUNWAY_ERROR
7006 CHASSIS_WRITE_BOMB_ERR
7007 CHASSIS_MEMORY_ADDRESS_
ERROR
7008 CHASSIS_MULTI_BIT_ERROR
7009 CHASSIS_SINGLE_BIT_ERROR
7fff CHASSIS_CATASTROPHIC_
MEM_ERR
70ff CHASSIS_UNKNOWN_HPMC
7101 CHASSIS_MMC_NOT_
RESPONDING
7102 CHASSIS_MMC_NOT_READY_
ERROR
7103 CHASSIS_MMC_FAILED_TO_
CLEAR
7104 CHASSIS_MMC_STICKY_BITS
7105 CHASSIS_MMC_BAD_REV
7106 CHASSIS_MMC_REG_ERROR
7107 CHASSIS_MMC_ERR_IN_
CPU_TEST
Notes
( 0x4040 to 0x4047 )
( 0x4060 to 0x4066 )
HPMC in memory system
Icache parity error
Dcache parity error
Memory MSI read error
Memory MSI write error
Runway error
Memory Write Bomb error
Memory address error
Memory multi bit error
Memory single bit error
Catastrophic memory
error
Unknown HPMC
MMC not responding
MMC not ready
MMC failed to clear
MMC bad revision
MMC register error
x = SMC number
