Memory DIMM Removal

Before removing memory DIMMs, open the system unit and remove the CPU assem-
bly.
Figure 5–12 shows the memory DIMM locations on the CPU Assembly. Figure 5–13
and Figure 5–14 show how to remove the memory DIMMs. Perform the following
steps to remove a memory DIMM from the system unit:
1. Locate the memory DIMMs on the CPU Assembly, shown in Figure 5–12.
Memory DIMMs
Memory DIMMs
Figure 5–12. Memory DIMM Location
Field Replaceable Units 5–19
