Gefen GEF-UHD-89-HBT2 User Manual

Gefen GEF-UHD-89-HBT2 User Manual

8x9 matrix for hdmi w/ hdcp 2.2, hdbaset & poh
Table of Contents

Advertisement

Quick Links

*Preferred
8x9 Matrix for HDMI
w/ HDCP 2.2, HDBaseT & POH
GEF-UHD-89-HBT2
User Manual
Release A1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GEF-UHD-89-HBT2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Gefen GEF-UHD-89-HBT2

  • Page 1 *Preferred 8x9 Matrix for HDMI w/ HDCP 2.2, HDBaseT & POH ™ GEF-UHD-89-HBT2 User Manual Release A1...
  • Page 2 Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this product near water. Clean only with a dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
  • Page 3 Gefen warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen is notified within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifications.
  • Page 4 Contacting Gefen Technical Support Technical Support (818) 772-9100 (800) 545-6900 8:00 AM to 5:00 PM Monday - Friday, Pacific Time (818) 772-9120 Email support@gefen.com http://www.gefen.com Mailing Address Gefen, LLC c/o Customer Service 20600 Nordhoff St. Chatsworth, CA 91311 Product Registration Register your product here: http://www.gefen.com/kvm/Registry/Registration.jsp...
  • Page 5 4K Ultra HD 8x9 Matrix for HDMI w/ HDCP 2.2, HDBaseT & POH is a trademark of Gefen, LLC. © 2015 Gefen, LLC. All Rights Reserved. All trademarks are the property of their respective owners. Gefen, LLC reserves the right to make changes in the hardware, packaging, and any accompanying documentation without prior written notice.
  • Page 6 Licensing This product uses software that is subject to open source licenses, including one or more of the General Public License Version 2 and Version 2.1, Lesser General Public License Version 2.1 and Version 3, BSD, and BSD-style licenses. Distribution and use of this product is subject to the license terms and limitations of liability provided in those licenses.
  • Page 7 • IP control via Telnet, UDP, and the built-in web server interface • IR remote control • Gefen Syner-G™ software’s Discovery and Show-Me features simplify initial IP configuration • Field-updatable firmware via web server interface • Can be placed on a shelf or mounted in a standard 19-inch wide rack...
  • Page 8 The 4K Ultra HD 8x9 Matrix for HDMI ships with the items listed below. The packing contents of the Sender and Receiver unit are listed below. If any of these items are not present in the box when you first open it, immediately contact your dealer or Gefen. •...
  • Page 9: Table Of Contents

    Table of Contents Getting Started Introduction......................2 Sender Unit - Front Panel ................2 Sender Unit - Rear Panel ................3 Receiver Unit ....................5 IR Remote Control ..................7 Installing the Batteries ................... 9 Setting the IR Channel ................10 Installation ......................11 Connection Instructions ................
  • Page 10 Table of Contents TCP / Telnet Settings .................. 57 UDP Settings ....................62 Discovery Settings ..................67 RS-232 Feedback ..................69 Adjusting the LCD Brightness ..............71 Setting the Matrix IR Channel ..............73 Resetting the Matrix ..................75 Rebooting the Matrix ................... 77 The Web Interface ....................
  • Page 11 This page left intentionally blank.
  • Page 12 This page left intentionally blank.
  • Page 13: Getting Started

    8x9 Matrix for HDMI w/ HDCP 2.2, HDBaseT & POH Getting Started...
  • Page 14: Introduction

    Sender Unit - Front Panel *Preferred Menu Preset ® Enter Power 4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH GEF-UHD-89-HBT2 HDBaseT™ POH Outputs HDMI RS-232 Ethernet IR In/Ext IR All Local Out RS-232 RS-232 RS-232...
  • Page 15: Sender Unit - Rear Panel

    Connect a grounding wire (16 AWG or greater) from this terminal to an approved ground path. IR In / Ext Connect an IR extender (Gefen part no. EXT-RMT-EXTIRN) or an electrical IR cable from an automation system to this port.
  • Page 16 Introduction Name Description RS-232 Connect the RS-232 cable from this port to an RS-232 device. See Connection Instructions (page 11) for more information. RS-232 (1 - 8) Connect a 3.5mm mini-stereo to DB-9 cable from each of these ports to the serial outputs on the RS-232 automation device.
  • Page 17: Receiver Unit

    HDBaseT™ POH Outputs HDMI RS-232 cal Out RS-232 RS-232 RS-232 RS-232 RS-232 RS-232 RS-232 IR In IR In Introduction IR In IR In IR In IR In IR In IR In IR In IR In IR In IR In IR In S-232 IR Out IR Out...
  • Page 18 Connect the included 3.5mm-to-DB-9 cable from this port to the RS-232 device to be controlled. IR In / Ext Connect an IR extender (Gefen part no. EXT-RMT-EXTIRN) or an electrical IR cable, from an automation system, to this port. IR Out Connect an IR emitter (Gefen part no.
  • Page 19: Ir Remote Control

    Introduction IR Remote Control Local Local Power Power Mask Mask Output Output Menu Menu Preset Preset Back Back Lock Lock Input Input *Preferred *Preferred ® ® RMT-89L RMT-89L Name Description Output buttons Press these buttons to select the desired (Local, A - H) output when performing routing operations.
  • Page 20 Introduction Name Description Input buttons (1- 8) / Off Press these buttons to select the desired input when performing routing operations. Each button corresponds to an In port (1 - 8) on the rear panel of the matrix. Press the Off button, followed by the number of the input (1 - 8) to “turn off”...
  • Page 21: Installing The Batteries

    Introduction Installing the Batteries Remove the back cover the IR remote control unit. Insert two 1.5V AAA-type batteries, as shown, within the battery compartment. Local Power Mask Output Menu Preset Back Lock Input *Preferred ® RMT-89L Replace the back cover. Warning! Risk of explosion if battery is replaced by an incorrect type.
  • Page 22: Setting The Ir Channel

    Introduction Setting the IR Channel Use the following DIP switch settings to set the IR channel of the IR remote control. In order for the included IR remote control to communicate with the matrix, the IR remote control must be set to the same channel as the matrix. Use the front panel to set the IR channel of the matrix.
  • Page 23: Installation

    Installation Connection Instructions ► Video Connect an HDMI cable from each 4K Ultra HD source device to the HDMI Input ports (1 - 8) on the rear panel of the matrix. Up to eight source devices can be connected. Connect a shielded CAT-5 (or better) cable from each HDBaseT POH Outputs ports (1 - 8), on the rear panel of the matrix, to each Receiver unit.
  • Page 24 13. Connect an IR emitter (Gefen part no. EXT-2IREMIT) to each of the IR Out ports on the rear panel of the matrix. 14. Connect an IR emitter (Gefen part no. EXT-2IREMIT) to the IR All Out port on the rear panel of the matrix.
  • Page 25: Application Diagram

    CAT-5 CABLE HDMI CABLE IR Extender RS-232 CABLE 4K Ultra HD Sources Automation Control Device GEF-UHD-89-HBT2 IR Emitters 4K Ultra HD 8x9 Matrix IR Blaster for HDMI w/ HDCP 2.2, HDBaseT & POH LAN/Network (for IP Control and Ethernet Extension)
  • Page 26: Network Configuration Using Syner-G

    Network Configuration using Syner-G Launch the Gefen Syner-G application. Download the application here: http://www.gefen.com/support/download.jsp Select the matrix (GEF-UHD-89-HBT2) from the list of products. Under the Device Settings section, select either Static or DHCP from the IP Mode drop-down list. ►...
  • Page 27 Installation Click the Save button at the bottom of the screen. The matrix will automatically reboot and use the new network settings. Use the IP address of the matrix to access the built-in web interface or start a Telnet session. See the following for more information: ►...
  • Page 28 This page left intentionally blank.
  • Page 29: Basic Operation

    8x9 Matrix for HDMI w/ HDCP 2.2, HDBaseT & POH Basic Operation...
  • Page 30: Powering The Matrix

    HDCP 2.2, HDBaseT™ & POH ® The first piece of information that is displayed is the model and current firmware. As of this writing, the current firmware is 0.2K. Be sure to check the Gefen website for the latest version of firmware. GEF-UHD-89-HBT2...
  • Page 31: Viewing The Routing Status

    4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH In 4 is currently routed to the display (sink device) that Local Power GEF-UHD-89-HBT2 is connected to Out D. HDBaseT™ POH Outputs HDMI Ethernet IR In/Ext IR All...
  • Page 32: Routing Inputs To Outputs

    A/V In:input 01 Enter Power 4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH out B :output B GEF-UHD-89-HBT2 A/V In:input 02 HDBaseT™ POH Outputs HDMI Ethernet IR In/Ext IR All Local Out RS-232...
  • Page 33 Routing Inputs to Outputs Press and release the ▲ or ▼ buttons to select the desired input. In this example, we will select Input 4. out G :output G )A/V In:input 04 Once the desired input is selected, press the Enter button. The arrow cursor, next to the input, will disappear indicating that the input can not be changed.
  • Page 34: Using The Ir Remote Control

    Routing Inputs to Outputs Using the IR Remote Control Go to the routing screen. If the routing screen is not displayed, then press and release the Back button on the IR remote control until the routing screen is displayed. Select the desired output by pressing one of the output buttons (Local, A - H) on the top-portion of the IR remote control.
  • Page 35: Using Ethernet

    In order to control matrix operation, provide access to the built-in web interface, and allow the extension of network devices, connect a shielded CAT-5 (or better) cable to the Ethernet / IP Control port from the rear panel of the matrix to the Local Area Network. GEF-UHD-89-HBT2 HDMI Ethernet...
  • Page 36: Ethernet Extension

    Connect a shielded CAT-5 (or better) cable to the Ethernet / IP Control port from the rear panel of the matrix to the Local Area Network. See IP Control (page 23) for more Enter Power GEF-UHD-89-HBT2 information. atrix for HDMI Back Lock HDBaseT™ POH Outputs ™...
  • Page 37: Using Rs-232

    Using RS-232 Controlling the Matrix To control the matrix using RS-232, connect a DB-9 cable from the automation control device to the RS-232 port on the rear panel of the matrix. GEF-UHD-89-HBT2 HDMI RS-232 Ethernet IR In/Ext IR All Local Out...
  • Page 38: Extending Rs-232

    Using RS-232 Extending RS-232 *Preferred Menu Preset ® This matrix allows the extension of RS-232 devices. Each RS-232 device is connected to a Receiver unit and can be extended up to 100 meters (330 feet). Baud rates up to 115200 are supported. Enter Begin by connecting up to eight 3.5mm cables from the automation control device to the HD 8x9 Matrix for HDMI...
  • Page 39: Ir Control

    IR In / Ext Port This port is used to control matrix routing and menu system operation. Connect either an IR extender (Gefen part no. EXT-RMT-EXTIRN) or an electrical IR cable, from a third-party automation control device, to this port.
  • Page 40: Ir All Out Port

    (or within the vicinity). However, only source devices that recognize the IR code will respond. If independent control of each source device is required, use the separate IR Out ports. IR Out Ports (page 31) for more information. GEF-UHD-89-HBT2 HDMI Ethernet IR In/Ext IR All...
  • Page 41: Ir All In Port

    IR emitter. Use this port to control a specified display (sink) device. Note that IR routing cannot be changed when using this port. To allow independent IR routing, separate from video routing, see the IR In Ports (page 30) section. GEF-UHD-89-HBT2 HDMI RS-232 Ethernet IR In/Ext...
  • Page 42: Ir In Ports

    Enter HD 8x9 Matrix for HDMI IR Control Lock Back 2, HDBaseT™ & POH IR In Ports The matrix includes eight separate IR In ports to control the display (sink) device. Connect an electrical IR cable from an automation control system to each of these ports. HDBaseT™...
  • Page 43: Ir Out Ports

    Enter Powe IR Control HD 8x9 Matrix for HDMI Back Lock 2, HDBaseT™ & POH IR Out Ports The matrix includes eight separate IR Out ports to control the source devices from the viewing location. Connect an IR emitter from each IR Out port to each source. The IR Out ports can be used independently of the video routing, if desired.
  • Page 44 IR Control In this illustration, we have two sources connected to the matrix. Source 1 is connected to HDMI Input 1 and Source 2 is connected to HDMI Input 2. We also have two IR emitters which are connected to IR Out 1 and IR Out 2. The IR remote for the source is pointed at the IR extender at viewing location 2 (Display 2) and we are controlling source that is connected to HDMI Input 2.
  • Page 45: Changing The Ir Routing State

    IR Control Changing the IR Routing State By default, the IR signal from each Receiver unit (output) is controlling its “associated” input source using the “Follow Input” mode. In other words, Output A > Input 1, Output B > Input 2, Output C > Input 3, and so on. This default IR routing state can be changed, independently of the A/V routing.
  • Page 46 Enter Power 4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH out A :output A Local Power GEF-UHD-89-HBT2 A/V In:input 01 HDBaseT™ POH Outputs HDMI Ethernet IR In/Ext IR All Local Out RS-232 RS-232...
  • Page 47 IR Control Select the desired input to be controlled by pressing and releasing the ▲ or ▼ buttons. To continue with our example, we will select Input 02. out A :output A )IR In :input 02 Press the Enter button on the front panel or the OK button on the IR remote control to accept the change.
  • Page 48: Masking Outputs

    Masking Outputs When masking outputs through the front panel, the IR remote control must be used. Outputs can also be masked by by using the built-in web interface. See Routing Inputs and Masking Outputs (page 88) for more information. When an output is masked, the signal is blocked at the output. Let’s say Input 02 is routed to Output A, Output B, and Output C.
  • Page 49: Blocking Inputs

    Blocking Inputs Blocking an input disables the input, preventing the source signal from reaching any of the outputs. For example, if Input 02 is routed to Output A, Output B, and Output C, then “blocking” Input 02 will prevent the A/V signal from being displayed on Output A, Output B, and Output C.
  • Page 50: Locking The Matrix

    :output a A/V In:input 01 Enter Power 4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH ► Unlocking the matrix GEF-UHD-89-HBT2 HDBaseT™ POH Outputs HDMI RS-232 Ethernet IR In/Ext IR All Local Out RS-232 RS-232...
  • Page 51: Using The Ir Remote Control

    Back Lock Menu Preset w/ HDCP 2.2, HDBaseT™ & POH Back Lock ► Unlocking the matrix GEF-UHD-89-HBT2 To unlock the matrix, press the Lock button on the HDBaseT™ POH Outputs HDMI RS-232 Ethernet IR In/Ext IR All Local Out RS-232...
  • Page 52: Routing Presets

    Enter Power 4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH The Preset selection screen will be displayed. GEF-UHD-89-HBT2 preset: 1 HDBaseT™ POH Outputs HDMI Ethernet IR In/Ext IR All Local Out...
  • Page 53 Routing Presets Using the IR Remote Control ► Start from any screen. Press the Preset button on the IR remote control. Use the set of Input buttons, from the bottom- portion of the IR remote control to select the Local Power desired preset.
  • Page 54: Menu System

    Enter Power 4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH out B :output B Local Power GEF-UHD-89-HBT2 A/V In:input 02 HDBaseT™ POH Outputs HDMI Ethernet IR In/Ext IR All Local Out RS-232 RS-232...
  • Page 55 ® out a :output a A/V In:input 01 Enter Power 4K Ultra HD 8x9 Matrix for HDMI Lock Back w/ HDCP 2.2, HDBaseT™ & POH GEF-UHD-89-HBT2 Information HDBaseT™ POH Outputs HDMI Ethernet IR In/Ext IR All Local Out RS-232 RS-232...
  • Page 56: Hpd Control

    Enter Power 4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH The Setup menu will be displayed: Local Power GEF-UHD-89-HBT2 HDBaseT™ POH Outputs HDMI Ethernet IR In/Ext IR All Local Out RS-232 RS-232 RS-232...
  • Page 57 Menu System The input selection screen will be displayed. Input 01 will be displayed, by default. hdp control: pulse: input 01 Press and release the ▲ or ▼ buttons on the front panel or on the IR remote control, to select the desired input. These buttons will glow blue when they are pressed on the front panel.
  • Page 58: Hdcp Control

    Enter Power 4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH The Setup menu will be displayed: Local Power GEF-UHD-89-HBT2 HDBaseT™ POH Outputs HDMI Ethernet IR In/Ext IR All Local Out RS-232 RS-232 RS-232...
  • Page 59 Menu System Press the Enter button on the front panel or on the IR remote control to display the input control screen. hdcp control: input input 01: 2.2 Press and release the ▲ or ▼ buttons on the front panel or on the included IR remote control, to select the desired input or output.
  • Page 60 Menu System 11. Press and release the ▲ or ▼ buttons on the front panel or on the IR remote control, to select the desired setting. input 03 )1.4 and below 12. Press the Enter button on the front panel or the OK button on the IR remote control to save the setting.
  • Page 61: Setting The Edid Mode

    Enter Power 4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH The Setup menu will be displayed: Local Power GEF-UHD-89-HBT2 HDBaseT™ POH Outputs HDMI Ethernet IR In/Ext IR All Local Out RS-232 RS-232 RS-232...
  • Page 62 Menu System Press the Enter button on the front panel or on the IR remote control to display the input control screen. Input 01 will be displayed by default. edid mode input 01 Press and release the ▲ or ▼ buttons on the front panel or on the IR remote control, to select the desired input.
  • Page 63 Menu System 11. Once the desired EDID has been selected, press the Enter button on the front panel or the OK button on the IR remote control. The input selection screen will be displayed. edid mode input 05 12. To set the EDID on another input, repeat steps 7 - 11. 13.
  • Page 64: Ip Settings

    Enter Power 4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH The Setup menu will be displayed: Local Power GEF-UHD-89-HBT2 HDBaseT™ POH Outputs setup HDMI Ethernet IR In/Ext IR All Local Out RS-232 RS-232...
  • Page 65 Menu System Setting the IP Mode ► From the IP Mode screen, press the Enter button on the front panel or the OK button on the IR remote control. An arrow cursor will be displayed next to the current IP mode, indicating that it can be changed: ip mode: )Static Press and release the ▲...
  • Page 66 Menu System Press the ▲ or ▼ buttons on the front panel or on the IR remote control, to change the numerical value of the digit (0 - 9). ip address: 092.168.001.072 Press the ◄ or ► buttons on the front panel or on the IR remote control to move between each digit in the IP address.
  • Page 67 Menu System Press the ▲ or ▼ buttons on the front panel or on the IR remote control, to change the numerical value of the digit (0 - 9). subnet mask: 255.255.055.000 After the desired address has been set, press the Enter button on the front panel or the OK button on the IR remote control to save the change.
  • Page 68 Menu System Press the ◄ or ► buttons on the front panel or on the IR remote control to move between each digit in the IP address. After the desired IP address has been set, press the Enter button on the front panel or the OK button on the IR remote control to save the change.
  • Page 69: Tcp / Telnet Settings

    Enter Power 4K Ultra HD 8x9 Matrix for HDMI Lock Back w/ HDCP 2.2, HDBaseT™ & POH The Setup menu will be displayed: Local Power GEF-UHD-89-HBT2 HDBaseT™ POH Outputs HDMI Ethernet IR In/Ext IR All Local Out RS-232 RS-232 RS-232...
  • Page 70 Menu System Enabling / Disabling TCP (Telnet) Access ► From the TCP access screen, press the Enter button on the front panel or the OK button on the IR remote control. tcp access: enabled Press the Enter button on the front panel or the OK button on the IR remote control to change the current setting.
  • Page 71 Menu System Setting the TCP Listening Port ► From the TCP access screen, press and release the ▲ or ▼ buttons on the front panel or on the IR remote control, to select the TCP Port option. The current TCP port will be displayed. tcp port: Press the Enter button on the front panel or the OK button on the IR remote control to edit the port number.
  • Page 72 Menu System Enabling / Disabling Telnet Welcome Message ► From the TCP access screen, press and release the ▲ or ▼ buttons on the front panel or on the IR remote control, to select the Login on Connect option. The current setting will be displayed. The default setting is enabled. login on connect: enabled Press the Enter button on the front panel or the OK button on the IR remote...
  • Page 73 Menu System Enabling / Disabling Password ► From the TCP access screen, press and release the ▲ or ▼ buttons on the front panel or on the IR remote control, to select the Require Password option. The current setting will be displayed. require password: disabled Press the Enter button on the front panel or the OK button on the IR remote...
  • Page 74: Udp Settings

    Enter Power 4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH The Setup menu will be displayed: Local Power GEF-UHD-89-HBT2 HDBaseT™ POH Outputs HDMI RS-232 Ethernet IR In/Ext IR All Local Out RS-232 RS-232...
  • Page 75 Menu System Enabling / Disabling UDP Access ► From the UDP access screen, press the Enter button on the front panel or the OK button on the IR remote control. An arrow cursor will be displayed next to the current setting, indicating that it can be changed: UDP access: disabled Press the Enter button on the front panel or the OK button on the IR remote...
  • Page 76 Menu System Setting the UDP Listening Port ► From the UDP Access screen, press and release the ▲ or ▼ buttons on the front panel or on the IR remote control, to select the UDP Port option. The current UDP port will be displayed. Udp port: 50007 Press the Enter button on the front panel or the OK button on the IR remote...
  • Page 77 Menu System Enabling / Disabling Remote UDP Access ► From the UDP Access screen, press and release the ▲ or ▼ buttons on the front panel or on the IR remote control, to select the Remote UDP Access option. The current setting will be displayed. remote UDP access: disabled Press the Enter button on the front panel or the OK button on the IR remote...
  • Page 78 Menu System Setting the Remote UDP Address ► From the UDP Access screen, press and release the ▲ or ▼ buttons on the front panel or on the IR remote control, to select the Remote UDP Address option. The current UDP address will be displayed. remote UDP address: 192.168.001.255 Press the Enter button on the front panel or the OK button on the IR remote...
  • Page 79: Discovery Settings

    Enter Power 4K Ultra HD 8x9 Matrix for HDMI Lock Back w/ HDCP 2.2, HDBaseT™ & POH The Setup menu will be displayed: Local Power GEF-UHD-89-HBT2 HDBaseT™ POH Outputs HDMI Ethernet IR In/Ext IR All Local Out RS-232 RS-232 RS-232...
  • Page 80 Menu System Press the Enter button on the front panel or the OK button on the IR remote control to change the current setting. The cursor will appear next to the current setting. discovery: )Enabled Press and release the ▲ or ▼ buttons on the front panel or on the IR remote control, to select the desired setting.
  • Page 81: Rs-232 Feedback

    Enter Power 4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH The Setup menu will be displayed: Local Power GEF-UHD-89-HBT2 setup HDBaseT™ POH Outputs HDMI Ethernet IR In/Ext IR All Local Out RS-232 RS-232...
  • Page 82 Menu System Press the Enter button on the front panel or the OK button on the IR remote control to change the current setting. The cursor will appear next to the current setting. rs-232 feedback: )Enabled Press and release the ▲ or ▼ buttons on the front panel or on the IR remote control, to select the desired setting.
  • Page 83: Adjusting The Lcd Brightness

    Enter Power 4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH The Setup menu will be displayed: Local Power GEF-UHD-89-HBT2 setup HDBaseT™ POH Outputs HDMI RS-232 Ethernet IR In/Ext IR All Local Out RS-232...
  • Page 84 Menu System Press the Enter button on the front panel or the OK button on the IR remote control to change the current setting. The cursor will appear next to the current setting. lcd brightness: Press and release the ▲ or ▼ buttons on the front panel or on the IR remote control, to select the desired setting.
  • Page 85: Setting The Matrix Ir Channel

    Enter Power 4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH The Setup menu will be displayed: Local Power GEF-UHD-89-HBT2 setup HDBaseT™ POH Outputs HDMI Ethernet IR In/Ext IR All Local Out RS-232 RS-232...
  • Page 86 Menu System Press the Enter button on the front panel or the OK button on the IR remote control to change the current IR channel. The cursor will appear next to the current IR channel. IR CHANNEL: Press and release the ▲ or ▼ buttons on the front panel or on the IR remote control, to select the desired IR channel.
  • Page 87: Resetting The Matrix

    Enter Power 4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH The Setup menu will be displayed: Local Power GEF-UHD-89-HBT2 setup HDBaseT™ POH Outputs HDMI Ethernet IR In/Ext IR All Local Out RS-232 RS-232...
  • Page 88 Menu System Press the Enter button on the front panel or the OK button on the IR remote control. The matrix will prompt to confirm the factory-reset operation. factory reset )yes Press and release the ▲ or ▼ buttons on the front panel or on the IR remote control, to select either Yes or No.
  • Page 89: Rebooting The Matrix

    Enter Power 4K Ultra HD 8x9 Matrix for HDMI Back Lock w/ HDCP 2.2, HDBaseT™ & POH The Setup menu will be displayed: Local Power GEF-UHD-89-HBT2 setup HDBaseT™ POH Outputs HDMI Ethernet IR In/Ext IR All Local Out RS-232 RS-232...
  • Page 90 Menu System Press the Enter button on the front panel or the OK button on the IR remote control. The matrix will prompt to confirm the factory-reset operation. reboot unit )yes Press and release the ▲ or ▼ buttons on the front panel or on the IR remote control, to select either Yes or No.
  • Page 91: The Web Interface

    The Web Interface Introduction to the Web Interface The 4K Ultra HD 8x9 Matrix for HDMI includes a built-in web interface. We recommend that the web interface be used to control the matrix as it provides easy management of all features used by the matrix.
  • Page 92 The Web Interface • Administrator The Administrator username provides full access to all features within the web interface. The default password for the Administrator user name is Admin. All passwords are case-sensitive. For information on changing the default password, see Configuring Network Settings (page 113).
  • Page 93 The Web Interface Tabs and Sub-tabs ► The web interface is organized into tabs, in the top-portion of the screen. Clicking on a tab will display a different screen. The Setup and Manage EDID tab have their own set of tabs, which we will refer to as “sub-tabs”, as shown below.
  • Page 94 The Web Interface • If a button is pale-yellow or pale-red (disabled), then this means that the setting is not available. This usually requires that another setting must be enabled before setting a “sub-set” of that feature. For example, note that both the Remote UDP Access button and the UDP Port field are disabled in the illustration, below: In order to change either of these settings, UDP Access must be enabled.
  • Page 95 The Web Interface Switch Audio / Video A dark blue square indicates that the input of that column is routed to the output of that row. Cyan-colored square indicates that the input and output are not routed to one another. See Routing Inputs and Masking Outputs (page 88) for more information.
  • Page 96: Controlling Power

    The Web Interface Controlling Power The current power status (ON or OFF) of the matrix is indicated next to the Power Off / Power On button in the web interface. ► If the matrix is powered-on, then the indicator will read Unit powered on, as shown below.
  • Page 97 The Web Interface Click the Power Off button to “turn off” the matrix. The following message box will be displayed, as the matrix powers-down. After a few moments, the web interface will reappear. Click the Power On button to “turn on” the matrix. The “Please wait, processing...”...
  • Page 98: Locking The Matrix

    The Web Interface Locking the Matrix Locking the matrix disables the front-panel controls, IR routing, and the built-in web interface. This is useful in preventing an accidental change to matrix settings by inadvertently pressing any of the front-panel buttons. Information Locking the Matrix Controller will also disable routing and other operations within the Web Interface.
  • Page 99: Viewing The Routing Status

    The Web Interface Viewing the Routing Status Click the Routing tab. Locate the desired output from the rows on the left, then read across until a routing indicator (dark-blue square) is encountered. Note the column where the dark-blue square is located. Each column identifies an input.
  • Page 100: Routing Inputs And Masking Outputs

    The Web Interface Routing Inputs and Masking Outputs Routing Inputs ► Click the Routing tab. Locate the desired output, from the left side of the screen. For this example, we will select Output C. Move the mouse horizontally, within the selected output row. As the mouse moves, the current output row and input column will be highlighted in yellow: Current input Current output...
  • Page 101 The Web Interface Routing indicator To “turn-off” an input, click the dark-gray square in the same row where the routing indicator for the input is located. In the example, above, Input 05 is routed to Output C. The routing indicator for Input 05 is located in the same row as Output C.
  • Page 102 The Web Interface Masking Outputs ► Click the Routing tab. Mask the desired output by clicking the Mask button. The Mask button will turn red, indicating that the selected output is masked. To unmask the output, click the Mask button again. The button will turn black. ►...
  • Page 103: Creating / Editing Routing Presets

    The Web Interface Creating / Editing Routing Presets Click the Routing tab. Under the Presets section, click the Preset Edit button. The screen will change and the Preset Edit button will read Choose One. page | 91...
  • Page 104 The Web Interface Click the desired preset to edit. In this example, we will select Preset_07. The selected preset will be highlighted. Select the desired routing state for each input/output. See Routing Inputs and Mask- ing Outputs (page 88), if necessary. The preset selections for the selected preset, will be indicated by a green square, as shown below.
  • Page 105 The Web Interface After the desired routing states, for input/output have been assigned, provide a name for the preset in the Preset Name field. ► To clear the preset selections for the current preset, click the Clear All button. ► To use the current routing state (dark blue squares) as the preset selection, click the Select Current button.
  • Page 106: Independent Ir Routing

    The Web Interface Independent IR Routing Normally, when an input is routed to an output, the IR routing is also changed. For example, in the illustration below, we have three blu-ray players. Blu-ray players Matrix Receiver units w/ IR extenders By default, the IR signal from each Receiver unit (output) is controlling its “associated”...
  • Page 107 The Web Interface Now, let’s say we want to control the blu-ray player, which is connected to Input 2, from any of the outputs (Output A - Output C). Click the IR Routing tab. Move the mouse over each square within the table. As the mouse moves, the current output row and input column will be highlighted in yellow.
  • Page 108 The Web Interface When a square is clicked (selected), it will turn dark green. Unselected Selected The new IR routing state will be applied immediately. If we revisit our original illustration, we can see that the blu-ray player, which is connected to Input 2 can now be controlled from any of the outputs.
  • Page 109: Ir Routing Presets

    The Web Interface IR Routing Presets Once we have defined an IR routing preset, we may want to save it for later use. This can be done by saving the current routing state to any one of 16 presets. After a preset has been saved, it can be edited or recalled for later use within the web interface.
  • Page 110 The Web Interface Click the Select Current button to select the current IR routing state. This will highlight the currently selected IR routing state (dark green squares) as orange squares. If we wanted to make a change to the currently selected IR routing state, we could manually click on the desired squares.
  • Page 111 The Web Interface The current IR routing state is now saved to the selected preset (Preset 1). To determine whether or not an IR preset is defined, select a preset from the drop-down list. If orange squares are present within the table, then this preset has been defined.
  • Page 112: Input And Output Status

    The Web Interface Input and Output Status Provides video and audio information for all inputs and outputs. Click the Status tab within the built-in web interface. Information on each input is listed in the top portion of the screen. This section is outlined in blue.
  • Page 113: Changing Input And Output Names

    The Web Interface Changing Input and Output Names By default, the names of each output are Output A - Output H. The names of each input are Input 1 - Input 8. Each of these names can be changed, as desired, to suit the type of device that is connected to the input or output.
  • Page 114: Hpd Control

    The Web Interface HPD Control HPD (Hot-Plug Detect) is an HDMI feature which senses if the HDMI cable is disconnected, from the source or sink device, and then re-initializes the HDMI link if necessary. Within the web interface, the HPD pulse can be sent to the selected input, and reset the HDMI connection without disconnecting any cables.
  • Page 115: Hdcp

    The Web Interface HDCP This feature allows HDCP content to either be passed-through or rejected on each input. Outputs can either follow the input status or can be set to always encode HDCP. Note that using the “Reject” feature, on an input, does not decrypt HDCP content. Click the Setup tab within the built-in web interface.
  • Page 116 The Web Interface For outputs, select the desired button next to the output. ► Follow Input - Click this button to have the output follow the setting used on the input. Click the Follow All button to set all outputs to Follow Input. ►...
  • Page 117: Setting The Edid Mode

    The Web Interface Setting the EDID Mode The EDID Mode tab allows the desired EDID mode (internal preset, external, or custom) to be set for each input. Click the Manage EDID tab within the built-in web interface. Click the EDID Mode sub-tab. Select the desired EDID mode for each input using the drop-down list.
  • Page 118 The Web Interface Using a Custom EDID ► The Custom - User-defined setting is used to store a custom EDID in the selected input. To use a custom EDID, follow the instructions below: Select Custom - User-defined from the drop-down list of the desired input. Copy or upload an EDID to the input that is using the Custom mode.
  • Page 119: Copying Edid Data

    The Web Interface Copying EDID Data The EDID Copy tab allows an EDID to be copied from an input or output (sink device) to any input. In order to copy an EDID to an input, the input must be set to Custom - User- defined mode and then unlocked.
  • Page 120 The Web Interface After the input or output is selected, click the button for the corresponding input where the EDID will be copied. One or more inputs can be selected at a time. Click the Copy button. The Copy can only be pressed when both an output or input (the source) and an input (destination) are selected.
  • Page 121: Getting Edid Information

    The Web Interface Getting EDID Information The EDID Info tab allows the EDID information, from an input or sink device, to be displayed. Click the Manage EDID tab within the built-in web interface. Click the EDID Info sub-tab. Select the desired input or output from the Choose EDID drop-down list. The EDID information for the selected input or output will be displayed.
  • Page 122: Uploading And Downloading Edid Data

    The Web Interface Uploading and Downloading EDID Data The Upload / Download tab allows EDID data from an input, output, or one of the internal EDID presets, to be downloaded and saved as a file on your computer. An EDID file can also be uploaded to any (unlocked) input.
  • Page 123 The Web Interface The following dialog will be displayed: Click the Save File button to save the EDID file to your computer. • Mac OS X The file will automatically be saved under Macintosh HD\Users\[username]\Downloads • Windows OS The file will be saved under C:\Users\[username]\Downloads page | 111...
  • Page 124 The Web Interface Uploading an EDID ► Click the Manage EDID tab within the built-in web interface. Click the Upload/Download sub-tab. Set the input, where the EDID file will be uploaded, to Custom mode. Setting the EDID Mode (page 105) for more information.
  • Page 125: Configuring Network Settings

    The Web Interface Configuring Network Settings Once the matrix is configured on the network using Gefen Syner-G, the network settings can be changed within the built-in web interface. To access the network settings, click the Network tab in the built-in web interface.
  • Page 126 The Web Interface TCP / Telnet Settings ► For details on configuring TCP, see Using Telnet, UDP, and RS-232 (page 130) • TCP Access: Click the Enable button to allow Telnet access to the matrix. Otherwise, click the Disable button. •...
  • Page 127 The Web Interface • User Name: This field is static and cannot be changed. Telnet sessions are restricted to Admin users. • Old Password: Enter the old (current) password in this field. The factory-default password is Admin. Passwords are case-sensitive. •...
  • Page 128 The Web Interface UDP Settings ► For details on configuring UDP, see Using Telnet, UDP, and RS-232 (page 130) • UDP Access: Click the Enable button to use the UDP protocol with the matrix. Otherwise, click the Disable button. • UDP Port: Enter the TCP listening port in this field.
  • Page 129 The Web Interface Web Login Settings ► • Username: To change the password for the Administrator, click the Administrator. Otherwise, click the Operator button. • New Password: Enter password for the selected username (above) in this field. Passwords are case-sensitive. •...
  • Page 130 • Product Description: GEF-UHD-89-HBT2 is the default product description. RS-232 IR Out IR Out IR Out This name will be used to identify the matrix when using the Gefen Syner-G IR Out IR Out IR Out IR Out IR Out HDMI Inputs software.
  • Page 131: System Settings

    The Web Interface System Settings The System tab provides controls for various other matrix features. Each of these controls is described below. ► Main RS-232 Feedback Click the Off button to disable RS-232 feedback. Click the On button to enable RS-232 feedback. LCD Brightness ►...
  • Page 132 The Web Interface Download Current Configuration to PC ► Saves the current matrix configuration to a file on your computer. Click the Download button. The following dialog box will be displayed: page | 120...
  • Page 133 The Web Interface Click the Save File button to save the EDID file to your computer. • Mac OS X The file will automatically be saved under Macintosh HD\Users\[username]\Downloads • Windows OS The file will be saved under C:\Users\[username]\Downloads ► Restore / Upload Configuration File Uploads the selected matrix configuration, from a file on your computer, to the matrix.
  • Page 134 Firmware Update ► Uploads and applies the latest firmware file to the matrix. Download the latest firmware from the Gefen web site. Click the Browse... button. Select the firmware file on your computer. The firmware must be a .bin file and will have the following naming convention: GEF-UHD-89-HBT2([version])(PACK).bin.
  • Page 135 The Web Interface After a few moments, the following message box will be displayed within the web interface: The Power button, on the front of the matrix, will flash red and blue and the update progress will be shown in the front-panel display: system updating After the update process completes, the matrix will automatically reboot.
  • Page 136 The Web Interface Setting the IR Channel ► Sets the IR channel for the matrix. The matrix must be set to the same IR channel as the included IR remote control, in order for the IR remote control to communicate with the matrix. Click the desired IR channel for the matrix by clicking one of the IR Channel buttons (1 - 4).
  • Page 137 The Web Interface Performing a Factory Reset ► This feature restores the matrix to original factory-default settings. Important Performing this function will erase all current setting in your matrix. IP settings will be retained. To save the configuration, before continuing, refer to the section Download Current Configuration to PC.
  • Page 138 The Web Interface Rebooting the matrix ► Clicking this button will reboot the matrix. Click the Reboot button. The following message box will be displayed: Click the OK button to continue with the reboot procedure. ► ► Click the Cancel button to abort the reboot procedure and return to the web interface.
  • Page 139 This page left intentionally blank.
  • Page 140 This page left intentionally blank.
  • Page 141: Advanced Operation

    8x9 Matrix for HDMI w/ HDCP 2.2, HDBaseT & POH Advanced Operation page | 129...
  • Page 142: Using Telnet, Udp, And Rs-232

    Using Telnet, UDP, and RS-232 Page Title Telnet Configuration Launch the desired terminal application on your platform: Windows or Mac OS X. The example, below, uses the Terminal application within Mac OS X. At the command prompt, type the following: telnet ip_address where ip_address is the IP address of the matrix.
  • Page 143: Rs-232 Configuration

    Using Telnet, UDP, and RS-232 RS-232 Configuration The following RS-232 settings are only required for controlling the matrix. When controlling RS-232 devices that are connected to Receiver units, consult the documentation for the RS-232 device. Launch the desired terminal application. Selected the desired COM port.
  • Page 144: Commands

    Commands Page Title Command Description #factory_reset Resets the matrix to factory-default settings #get_device_desc Returns the current device-description string #get_discovery Returns the current state of the discovery service #get_discovery_mode Returns the “discovery” mode #get_edid_lock Returns the EDID-lock status of the specified input #get_edid_mode Returns the EDID mode of the specified input #get_gateway...
  • Page 145 Commands Page Title Command Description #set_discovery_mode Sets the “discovery” mode #set_edid_copy Enables or disables EDID copy #set_edid_lock Sets the EDID lock setting on the specified input #set_edid_mode Sets the EDID mode on the specified input #set_feedback Enables or disables unsolicited RS-232 feedback #set_gateway Sets the gateway address #set_hdbt_distance...
  • Page 146 Commands Page Title #factory_reset Resets the matrix to factory-default settings. If a factory reset is performed through the built-in web interface or Telnet, then IP settings will be preserved. To reset all, including IP settings, this command must be issued using RS-232. Syntax #factory_reset Parameters...
  • Page 147 Commands Page Title #get_device_desc Returns the description of the matrix. Syntax #get_device_desc Parameters None Example #get_device_desc DEVICE DESCRIPTION IS GTB-UHD-89-HBT2 Related Commands #set_device_desc page | 135...
  • Page 148 Commands Page Title #get_discovery Returns the discovery mode setting. The value returned is one of the following: Value Description “Discovery” mode is disabled “Discovery” mode is enabled Syntax #get_discovery Parameters None Example #get_discovery DISCOVERY 1 Related Commands #set_discovery #set_showme page | 136...
  • Page 149 Commands Page Title #get_discovery_mode Returns the current “discovery” mode. The value returned is one of the following: Value Description Read only Read / Write Syntax #get_discovery_mode Parameters None Example #get_discovery_mode #get_discovery_mode 1 Related Commands #get_discovery #set_discovery #set_discovery_mode page | 137...
  • Page 150 Commands Page Title #get_edid_lock Returns the current “EDID Lock” state of the specified input. The value returned is one of the following: Value Description EDID unlocked EDID locked Syntax #get_edid_lock input Parameters input Type: INTEGER The number of the HDMI input (1 - 8) to query. Example #get_edid_lock 1 EDID_LOCK 1 0...
  • Page 151 Commands Page Title #get_edid_mode Returns the EDID mode of the specified input. The value returned is one of the following: Value Description Internal 720p 2Ch Internal 720p Multi-Ch Internal 1080p 2Ch Internal 1080p Multi-Ch Internal UHD 2Ch Internal UHD Multi-Ch External (Output A) Custom Syntax...
  • Page 152 Commands Page Title #get_gateway Returns the gateway address of the matrix. Syntax #get_gateway Parameters None Example #get_gateway GATEWAY 10.5.64.1 Related Commands #get_http_port #get_ip_address #get_ip_mode #get_ipconfig #get_mac_addr #get_netmask #set_gateway #set_http_port #set_ip_address #set_ip_mode #set_netmask page | 140...
  • Page 153 Commands Page Title #get_hdbt_distance Returns the HDBaseT distance setting for the specified output. The value returned is one of the following: Value Description Normal mode Long-reach mode Syntax #get_hdbt_distance output Parameters output Type: CHARACTER The identifier of the HDMI output (A - H) to query. Example #get_hdbt_distance a HDBT_DISTANCE A 1...
  • Page 154 Commands Page Title #get_hdbt_ir Returns the IR setting for the specified output. The value returned is one of the following: Value Description Carrier signal is stripped Carrier signal is intact Carrier signal has been inserted Syntax #get_hdbt_ir output tofrom Parameters output Type: CHARACTER The identifier of the HDMI output (A - H) to query.
  • Page 155 Commands Page Title #get_http_port Returns the HTTP listening port of the matrix. Syntax #get_http_port Parameters None Example #get_http_port HTTP_PORT 80 Related Commands #get_gateway #get_ip_address #get_ip_mode #get_ipconfig #get_mac_addr #get_netmask #set_gateway #set_http_port #set_ip_address #set_ip_mode #set_netmask page | 143...
  • Page 156 Commands Page Title #get_input_hdcp Returns the HDCP mode of the specified input. The value returned is one of the following: Value Description Reject HDCP 2.2 and below HDCP 1.4 and below Syntax #get_input_hdcp input Parameters input Type: INTEGER The number of the HDMI input (1 - 8) to query. Example #get_input_hdcp 1 INPUT_HDCP 1 0...
  • Page 157 Commands Page Title #get_io_name Returns the name given to the specified input or output. Syntax #get_io_name inout Parameters input Type: INTEGER or CHARACTER The number of the HDMI input (1 - 8) to query. Example #get_io_name 1 IO_NAME 1 Bluray Related Commands #set_io_name page | 145...
  • Page 158 Commands Page Title #get_ip_address Returns the current IP address of the matrix. Syntax #get_ip_address Parameters None Example #get_ip_address IP_ADDRESS 10.5.64.81 Related Commands #get_gateway #get_http_port #get_ip_mode #get_ipconfig #get_mac_addr #get_netmask #set_gateway #set_http_port #set_ip_address #set_ip_mode #set_netmask page | 146...
  • Page 159 Commands Page Title #get_ip_mode Returns the current IP mode of the matrix. The value returned is one of the following: Value Description Static mode DHCP mode Syntax #get_ip_mode Parameters None Example #get_ip_mode IP_MODE 0 Related Commands #get_gateway #get_http_port #get_ip_address #get_ipconfig #get_mac_addr #get_netmask #set_gateway...
  • Page 160 Commands Page Title #get_ipconfig Returns the current IP configuration of the matrix. In addition to providing the MAC address and the broadcast IP address, this command also provides the same information as executing the #get_ip_address, #get_netmask, #get_gateway, #get_mac_addr ommands. Syntax #get_ipconfig Parameters None...
  • Page 161 Commands Page Title #get_ir_channel Returns the IR channel of the matrix. Syntax #get_ir_channel Parameters None Example #get_ir_channel IR_CHANNEL 1 Related Commands #set_ir_channel page | 149...
  • Page 162 Commands Page Title #get_lcd_brightness Returns the brightness level of the front-panel display. Syntax #get_lcd_brightness Parameters None Example #get_lcd_brightness LCD_BRIGHTNESS 60 Related Commands #set_lcd_brightness page | 150...
  • Page 163 Commands Page Title #get_mac_addr Returns the MAC address of the matrix. Syntax #get_mac_addr Parameters None Example #get_mac_addr MAC ADDRESS IS: 00:1C:91:04:90:03 Related Commands #get_gateway #get_http_port #get_ip_address #get_ip_mode #get_ipconfig #get_netmask #set_gateway #set_http_port #set_ip_address #set_ip_mode #set_netmask page | 151...
  • Page 164 Commands Page Title #get_netmask Returns the current subnet mask of the matrix. Syntax #get_netmask Parameters None Example #get_netmask NETMASK 255.255.255.0 Related Commands #get_gateway #get_http_port #get_ip_address #get_ip_mode #get_ipconfig #get_mac_addr #set_gateway #set_http_port #set_ip_address #set_ip_mode #set_netmask page | 152...
  • Page 165 Commands Page Title #get_output_hdcp Returns the HDCP setting of the specified output. The value returned is one of the following: Value Description Follow input Always encode Syntax #get_output_hdcp output Parameters output Type: CHARACTER The identifier of the HDMI output (A - H) to query. Example #get_output_hdcp c OUTPUT_HDCP C 1...
  • Page 166 Commands Page Title #get_power Returns the current power state of the matrix. The value returned is one of the following: Value Description Power off Power on Syntax #get_power Parameters None Example #get_power POWER 1 Related Commands #power page | 154...
  • Page 167 Commands Page Title #get_preset_name Returns the name of the specified preset. Syntax #get_preset_name preset Parameters preset Type: INTEGER The identifier of the preset name (1 - 16) to query. Example #get_preset_name 5 PRESET_NAME 5 Kitchen Related Commands #set_preset_name page | 155...
  • Page 168 Commands Page Title #get_remote_udp_access Returns the remote UDP access state. The value returned is one of the following: Value Description Remote UDP access disabled Remote UDP access enabled Syntax #get_remote_udp_access Parameters None Example #get_remote_udp_access REMOTE_UDP_ACCESS 0 Related Commands #get_remote_udp_ip #get_remote_udp_port #get_udp_access #get_udp_port #set_remote_udp_access...
  • Page 169 Commands Page Title #get_remote_udp_ip Returns the remote UDP IP address. Syntax #get_remote_udp_ip Parameters None Example #get_remote_udp_access REMOTE_UDP_IP 192.168.1.255 Related Commands #get_remote_udp_access #get_remote_udp_port #get_udp_access #get_udp_port #set_remote_udp_access #set_remote_udp_ip #set_remote_udp_port #set_udp_access #set_udp_port page | 157...
  • Page 170 Commands Page Title #get_remote_udp_port Returns the remote UDP listening port. Syntax #get_remote_udp_port Parameters None Example #get_remote_udp_port REMOTE_UDP_PORT 50008 Related Commands #get_remote_udp_access #get_remote_udp_ip #get_udp_access #get_udp_port #set_remote_udp_access #set_remote_udp_ip #set_remote_udp_port #set_udp_access #set_udp_port page | 158...
  • Page 171 Commands Page Title #get_telnet_access Returns the Telnet access state. Use the #set_telnet_access command to enable or disable Telnet access. Syntax #get_telnet_access Parameters None Example #get_telnet_access TELNET_ACCESS 1 Related Commands #get_telnet_port #get_telnet_welcome #set_telnet_access #set_telnet_port #set_telnet_welcome #use_telnet_login page | 159...
  • Page 172 Commands Page Title #get_telnet_port Returns the Telnet listening port. Syntax #get_telnet_port Parameters None Example #get_telnet_port TELNET_PORT 23 Related Commands #get_telnet_access #get_telnet_welcome #set_telnet_access #set_telnet_port #set_telnet_welcome #use_telnet_login page | 160...
  • Page 173 Commands Page Title #get_telnet_welcome Returns the Telnet welcome message. Use the #set_telnet_welcome to create a custom welcome message. Syntax #get_telnet_welcome Parameters None Example #get_telnet_welcome TELNET WELCOME SCREEN IS ENABLED Related Commands #get_telnet_access #get_telnet_port #set_telnet_access #set_telnet_port #set_telnet_welcome #use_telnet_login page | 161...
  • Page 174 Commands Page Title #get_udp_access Returns the UDP access state. Use the #set_udp_access command to enable or disable UDP access. The value returned is one of the following: Value Description UDP access disabled UDP access enabled Syntax #get_udp_access Parameters None Example #get_udp_access UDP_ACCESS 0 Related Commands...
  • Page 175 Commands Page Title #get_udp_port Returns the local UDP listening port. Syntax #get_udp_port Parameters None Example #get_udp_port UDP_PORT 50007 Related Commands #get_remote_udp_access #get_remote_udp_ip #get_remote_udp_port #get_udp_access #set_remote_udp_access #set_remote_udp_ip #set_remote_udp_port #set_udp_access #set_udp_port page | 163...
  • Page 176 Commands Page Title #help Returns a list of available commands. The commands listed are specific to either the Sender or Receiver unit. Syntax #help Parameters None Example #help [Presets] #SET_PRESET_NAME #GET_PRESET_NAME [Setup] #SET_IO_NAME #GET_IO_NAME #SEND_HPD #SET_INPUT_HDCP #GET_INPUT_HDCP #SET_OUTPUT_HDCP #GET_OUTPUT_HDCP [MANAGE EDID] #SET_EDID_MODE #GET_EDID_MODE #SET_EDID_LOCK...
  • Page 177 Commands Page Title #lock_matrix Locks or unlocks the matrix. This command locks the front panel and the built-in web interface of the matrix. Note that if the matrix is locked, settings can still be changed using the command set. Syntax #lock_matrix state Parameters state...
  • Page 178 Commands Page Title #power Powers the unit ON or OFF. Syntax #power state Parameters state Type: INTEGER Accepts a number from the table below, specifying the desired state: state Description Power-OFF the matrix Power-ON the matrix Example #power 1 POWER 1 Related Commands #get_power page | 166...
  • Page 179 Commands Page Title #reboot Reboots the matrix. Syntax #reboot Parameters None Example #reboot UNIT WILL REBOOT SHORTLY Related Commands #factory_reset page | 167...
  • Page 180 Commands Page Title #send_hpd Sends an HPD (Hot-Plug Detect) pulse to the specified input. Syntax #send_hpd input Parameters input Type: INTEGER The identifier of the HDMI input (1 - 8) where the HPD pulse will be sent. Example #send_hpd 1 HPD SENT Related Commands page | 168...
  • Page 181 Commands Page Title #set_device_desc Sets the matrix identifier string. Syntax #set_device_desc name Parameters name Type: STRING The device description. This value cannot exceed 30 characters in length. Example #set_device_desc matrix202 DEVICE DESCRIPTION IS SET TO matrix202 Related Commands #get_device_desc page | 169...
  • Page 182 Commands Page Title #set_discovery Enables or disables the “discovery” feature. This feature is enabled by default. Syntax #set_discovery state Parameters state Type: INTEGER Accepts a number from the table below, specifying the desired state: state Description Disables “Discovery” mode Enables “Discovery” mode If set to disabled, then the Syner-G Software Suite will be unable to detect the matrix on a network.
  • Page 183 Read / write mode When set to read-only mode, the IP settings for the matrix will be displayed within the Gefen Syner-G Software Suite but cannot be changed. In order to both display and allow changes to the IP settings within Gefen Syner-G, set this feature to read/write mode.
  • Page 184 Commands Page Title #set_edid_copy Copies the EDID from output or input to the selected input for use in custom EDID mode. In order for an EDID to be copied, the destination input port must be set to Custom mode and must not be locked. See Copying EDID Data (page 107) for more information.
  • Page 185 Commands Page Title #set_edid_lock Locks to unlocks the EDID when using Custom EDID mode. This command only works if the specified input is set to Custom. See the #set_edid_mode command. Syntax #set_edid_lock input state Parameters input Type: INTEGER This parameter must be the identifier of an HDMI input (1 - 8). state Type: INTEGER Accepts a number from the table below, specifying the desired state:...
  • Page 186 Commands Page Title #set_edid_mode Sets the EDID mode for the specified input. Syntax #set_edid_mode input mode Parameters input Type: INTEGER This parameter must be the identifier of an HDMI input (1 - 8). mode Type: INTEGER Accepts a number from the table below, corresponding to the desired EDID. mode Description Internal 720p 2Ch...
  • Page 187 Commands Page Title #set_feedback Enables or disables unsolicited RS-232 feedback. Syntax #set_feedback state Parameters state Type: INTEGER Accepts a number from the table below, specifying the desired state: state Description Disable RS-232 feedback Enable RS-232 feedback Example #set_feedback 1 SET_FEEDBACK 1 page | 175...
  • Page 188 Commands Page Title #set_gateway Sets the gateway address for the matrix. The gateway address will be changed only if the matrix is in static IP mode. If the matrix is using DHCP mode, then the gateway address is automatically assigned by the DHCP server. The matrix must be rebooted after executing this command.
  • Page 189 Commands Page Title #set_hdbt_distance Sets the HDBaseT distance setting for the specified output. Syntax #set_hdbt_distance output mode Parameters output Type: CHARACTER The identifier of the HDMI output (A - H) to use. mode Type: INTEGER Accepts a number from the table below, specifying the HDBaseT mode: mode Description Normal mode...
  • Page 190 Commands Page Title #set_hdbt_ir Sets the IR setting for the specified output. Syntax #set_hdbt_ir output tofrom signal Parameters output Type: CHARACTER The identifier of the HDMI output (A - H) to use. tofrom Type: INTEGER Accepts a number from the table below, specifying the desired adjustment: tofrom Description IR signal from the Receiver unit...
  • Page 191 Commands Page Title #set_http_port Sets the HTTP listening port for the matrix. Syntax #set_gateway port Parameters port Type: INTEGER The desired HTTP listening port for the matrix. Example #set_gateway 192.168.1.1 GATEWAY 192.168.1.1 Related Commands #get_gateway #get_http_port #get_ip_address #get_ip_mode #get_ipconfig #get_mac_addr #get_netmask #set_gateway #set_ip_address...
  • Page 192 Commands Page Title #set_input_hdcp Sets the HDCP mode on the specified input. Syntax #set_input_hdcp input mode Parameters input Type: INTEGER Accepts the number of an HDMI input (1 - 8). mode Type: INTEGER Accepts a number from the table below, corresponding to the desired HDCP mode.
  • Page 193 Commands Page Title #set_io_name Sets the name of the specified input. Syntax #set_io_name inout name Parameters inout Type: INTEGER or CHARACTER This parameter can accept either the number of an HDMI input (1 - 8) or the identifier or an HDMI output (A - H). Only one input or output can be specified at one time.
  • Page 194 Commands Page Title #set_ip_address Sets the IP address of the matrix. The matrix must be rebooted after executing this command. Syntax #set_ip_address addr Parameters addr Type: IP ADDRESS The desired IP address of the matrix. This address must be entered in dot-decimal notation.
  • Page 195 Commands Page Title #set_ip_mode Sets the IP mode of the matrix. The matrix must be rebooted after executing this command. Syntax #set_ip_mode mode Parameters mode Type: INTEGER Accepts a number from the table below, corresponding to the desired IP mode. mode Description Static...
  • Page 196 Commands Page Title #set_ir_channel Sets the IR channel of the matrix. In order to use the included IR remote control with the matrix, both the matrix and the IR remote control must be set to the same IR channel. Syntax #set_ir_channel irch Parameters irch...
  • Page 197 Commands Page Title #set_lcd_brightness Sets the brightness level of the display on the front panel of the matrix. Syntax #set_lcd_brightness level Parameters level Type: INTEGER Accepts a number within the range of 0 - 100. The value of 100 represents the brightest setting of the display.
  • Page 198 Commands Page Title #set_netmask Sets the network mask address. The matrix must be rebooted after executing this command. Syntax #set_netmask addr Parameters addr Type: ADDRESS The desired subnet mask of the matrix. This address must be entered in dot-decimal notation. Example #set_netmask 255.255.255.0 NETMASK 255.255.255.0...
  • Page 199 Commands Page Title #set_output_hdcp Sets the HDCP mode on the specified output. Syntax #set_output_hdcp output mode Parameters output Type: CHARACTER Accepts the identifier of an HDMI output (A - H). mode Type: INTEGER Accepts a number, from table below, corresponding to the desired HDCP mode. mode Description Follow Input...
  • Page 200 Commands Page Title #set_preset_name Assigns a name to the specified preset. Syntax #set_present_name preset name Parameters preset Type: INTEGER Accepts the identifier of a Preset (1 - 16). name Type: STRING The name of the preset. The name must not exceed 12 characters in length. No special characters (e.g.
  • Page 201 Commands Page Title #set_remote_udp_access Enables or disables remote UDP access. Syntax #set_remote_udp_access state Parameters state Type: INTEGER Accepts a number from the table below, corresponding to the desired state. state Description Disable remote UDP access Enable remote UDP access Example #set_remote_udp_access 0 REMOTE_UDP_ACCESS 0 Related Commands...
  • Page 202 Commands Page Title #set_remote_udp_ip Sets the remote UDP IP address of the matrix. Syntax #set_remote_udp_ip addr Parameters addr Type: IP ADDRESS The desired remote UDP IP address of the matrix. The address must be entered in dot-decimal notation. Example #set_remote_udp_ip 192.168.1.251 REMOTE_UDP_IP 192.168.1.251 Related Commands #get_remote_udp_access...
  • Page 203 Commands Page Title #set_remote_udp_port Sets the remote UDP listening port for the matrix. Syntax #set_remote_udp_port port Parameters port Type: INTEGER The desired remote UDP port (0 - 65535) of the matrix. Example #set_remote_udp_port 50008 REMOTE_UDP_PORT 50008 Related Commands #get_remote_udp_access #get_remote_udp_ip #get_remote_udp_port #get_udp_access #get_udp_port...
  • Page 204 Commands Page Title #set_showme Enables or disables the “Show Me” feature. If the “Show Me” feature is enabled, then all the buttons (with the exception of the Power button), will flash slowly. This feature allows the matrix to be visually identified on the network and is useful when multiple matrix units are being used.
  • Page 205 Commands Page Title #set_telnet_access Enables or disables Telnet access on the matrix. Syntax #set_telnet_access state Parameters state Type: INTEGER Accepts a number from the table below, corresponding to the desired state. state Description Disable Telnet access Enable Telnet access Example #set_telnet_access 1 TELNET_ACCESS 1 Related Commands...
  • Page 206 Commands Page Title #set_telnet_port Sets the Telnet listening port on the matrix. Syntax #set_telnet_port port Parameters port Type: INTEGER The desired remote Telnet listening port (0 - 65535) of the matrix. Example #set_telnet_port 23 TELNET_PORT 23 Related Commands #get_telnet_access #get_telnet_port #get_telnet_welcome #set_telnet_access #set_telnet_welcome...
  • Page 207 Commands Page Title #set_telnet_welcome Enables or disables the Telnet welcome message. Syntax #set_telnet_welcome state Parameters state Type: INTEGER Accepts a number, from table below, corresponding to the desired state. state Description Disable welcome message Enable welcome message Example #set_telnet_welcome 1 TELNET WELCOME SCREEN IS ENABLED Related Commands #get_telnet_access...
  • Page 208 Commands Page Title #set_udp_access Enables or disables UDP access. Syntax #set_udp_access state Parameters state Type: INTEGER Accepts a number, from table below, corresponding to the desired state. state Description Disable UDP access Enable UDP access Example #set_udp_access 0 UDP_ACCESS 0 Related Commands #get_remote_udp_access #get_remote_udp_ip...
  • Page 209 Commands Page Title #set_udp_port Sets the local UDP listening port. Syntax #set_udp_port port Parameters port Type: INTEGER The desired UDP listening port (0 - 65535) of the matrix. Example #set_udp_port 50007 UDP_PORT 50007 Related Commands #get_remote_udp_access #get_remote_udp_ip #get_remote_udp_port #get_udp_access #get_udp_port #set_remote_udp_access #set_remote_udp_ip #set_remote_udp_port...
  • Page 210 Commands Page Title #show_firmware_version Returns the firmware version of the matrix. The returned value will depend upon the version of firmware that is currently installed. Syntax #show_firmware_version Parameters None Example #show_firmware_version FIRWMARE VERSION IS V0.2B page | 198...
  • Page 211 Commands Page Title #use_telnet_login Enables or disables login credentials when starting a Telnet session. Syntax #use_telnet_login state Parameters state Type: INTEGER Accepts a number, from table below, corresponding to the desired state. state Description Disable Telnet login Enable Telnet login Example #use_telnet_login 0 USE_TELNET_LOGIN 0...
  • Page 212 Commands Page Title Routes IR data from any Receiver Unit to any input. Up to eight outputs can be specified at a time. Syntax ir input output [...output] Parameters input Type: INTEGER The desired input (1 - 8) on the matrix. To have the IR routing follow the input routing, set this parameter to 0.
  • Page 213 Commands Page Title Enables or disables masking on the specified output(s). Syntax m state output [...output] Parameters state Type: INTEGER Accepts a number from the table below, corresponding to the desired state. state Description Disable masking Enable masking output Type: CHARACTER The identifier of an HDMI output (A - H).
  • Page 214 Commands Page Title Recalls the specified routing preset. Syntax p preset Parameters preset Type: INTEGER The number of a preset (1 - 16). Example p 10 P 10 Related Commands page | 202 page | 202...
  • Page 215 Commands Page Title Routes the specified input to the one or more specified outputs. Syntax r input output [...output] Parameters input Type: INTEGER / STRING The number of an HDMI input (1 - 8). This parameter also accepts a string argument of “OFF”.
  • Page 216 This page left intentionally blank.
  • Page 217: Appendix

    8x9 Matrix for HDMI w/ HDCP 2.2, HDBaseT & POH Appendix page | 205...
  • Page 218: Network Cable Diagram

    Network Cable Diagram Front of RJ-45 Connector 1 2 3 4 5 6 7 8 Gefen recommends the TIA/EIA-568-B wiring option. Use the table below when field-terminating cable for use with Gefen products. Color Description Orange / White TD+ (Transmit Data, positive differential signal)
  • Page 219: Default Settings

    Remote UDP Port 50008 Administrator Password (default) Admin Operator Password (default) Operator Enable Discovery (Gefen Syner-G) Enabled Find Your Device (Gefen Syner-G) Hide Me Discover Read Only (Gefen Syner-G) Read / Write Product Description (Gefen Syner-G) GEF-UHD-89-HBT2 Description Setting Output Names...
  • Page 220 Default Settings Description Setting Routing Input 1 > Output A Input 2 > Output B Input 3 > Output C Input 4 > Output D Input 5 > Output E Input 6 > Output F Input 7 > Output G Input 8 >...
  • Page 221: Internal Edid Profiles

    Internal EDID Profiles 720p 2-channel audio Video data block 1280x720p @ 60Hz (16:9) 1280x720p @ 50Hz (16:9) 640x480p @ 60Hz (4:3) 720x480p @ 60Hz (16:9) 720x480p @ 60Hz (4:3) 1440x480p @ 60Hz (4:3) 1440x480p @ 60Hz (16:9) 720x576p @ 50Hz (4:3) 1440x480i @ 60Hz (4:3) 1440x480i @ 60Hz (16:9) 720x576p...
  • Page 222 Internal EDID Profiles 1080p 2-channel audio Video data block 640x480p @ 60Hz (4:3) 720x480p @ 60Hz (16:9) 720x480p @ 60Hz (16:9) 1280x720p @ 60Hz (16:9) 1920x1080i @ 60Hz (16:9) 1440x480i @ 60Hz (4:3) 1440x480i @ 60Hz (16:9) 1440x480p @ 60Hz (4:3) 1440x480p @ 60Hz (16:9) 720x576p...
  • Page 223 Internal EDID Profiles 1080p Multichannel audio Video data block 640x480p @ 60Hz (4:3) 720x480p @ 60Hz (16:9) 720x480p @ 60Hz (16:9) 1280x720p @ 60Hz (16:9) 1920x1080i @ 60Hz (16:9) 1440x480i @ 60Hz (4:3) 1440x480i @ 60Hz (16:9) 1440x480p @ 60Hz (4:3) 1440x480p @ 60Hz (16:9) 720x576p...
  • Page 224 Internal EDID Profiles 4K 2-channel audio Video data block 720x480p @ 60Hz 1280x720p @ 60Hz (16:9) 1920x1080i @ 60Hz (16:9) 1440x480i @ 60Hz (16:9) 1920x1080p @ 60Hz (16:9) 720x576p @ 50Hz (16:9) 1280x720p @ 50Hz (16:9) 1920x1080i @ 50Hz (16:9) 1440x576i @ 50Hz (16:9) 1920x1080p @ 50Hz (16:9)
  • Page 225 Internal EDID Profiles 4K multichannel audio Video data block 720x480p @ 60Hz 1280x720p @ 60Hz (16:9) 1920x1080i @ 60Hz (16:9) 1440x480i @ 60Hz (16:9) 1920x1080p @ 60Hz (16:9) 720x576p @ 50Hz (16:9) 1280x720p @ 50Hz (16:9) 1920x1080i @ 50Hz (16:9) 1440x576i @ 50Hz (16:9) 1920x1080p @ 50Hz (16:9)
  • Page 226: Specifications

    Specifications Supported Formats Resolutions (max.) • 4096 x 2160 at 24 or 30 Hz • 3860 x 2160 at 60 Hz (4:2:0) • 1080p Full HD • 1920 x 1200 (WUXGA) Connectors, Controls, and Indicators (Matrix) HDMI In • 8 x Type A 19-pin female, locking HDMI Out •...
  • Page 227 Specifications Operational Maximum pixel clock • 300 MHz Power Consumption • 175 W Operating temperature • +32 to +122 ºF (0 to +50 ºC) Operating humidity • 5% to 90% RH, non-condensing Storage temperature • -4 to +140 ºF (-20 to +60 ºC) Storage humidity •...
  • Page 228: Index
