Summary of Contents for Gefen GTV-HDMI1.3-441
- Page 1 4x1 Gefen TV Switcher GTV-HDMI1.3-441 User Manual www.gefentv.com...
- Page 2 Notice Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. 4x1 Gefen TV Switcher is a trademark of Gefen Inc. HDMI™ is a trademark of HDMI.org...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction / Operation Notes Features / HDMI 1.3 Features / Package Includes Panel Descriptions Connecting and Operating the 4x1 Gefen TV Switcher / Device Buttons / Automatic Switching GTV4-IR Installation IR Code Confi guration Wiring Diagram Specifi cations... -
Page 4: Introduction / Operation Notes
Gefen TV Gefen TV is a unique product line catering to the growing needs for innovative home theater solutions. We specialize in total integration for your home theater, while also focusing on going above and beyond customer expectations to en- sure you get the most from your hardware. -
Page 5: Features / Hdmi 1.3 Features / Package Includes
Deep Color Supported (XV Color Supported) • Dolby TrueHD & DTS HD Master Audio Supported • CEC Pass Through Package Includes (1) Gefen TV Switcher (1) 6' HDMI cable (M-M) (1) 5V DC Power Supply (1) GTV4-IR Remote Control (1) User Manual... -
Page 6: Panel Descriptions
PANEL DESCRIPTIONS Power and Channel LED Indicators IR Eye EQ and Input HDMI Input 1 Input 2 Input 3 Input 4 Button Output Power Supply Input... -
Page 7: Connecting And Operating The 4X1 Gefen Tv Switcher / Device Buttons / Automatic Switching
AUTOMATIC SWITCHING Automatic switching is done very easily. Whenever a connected device is powered on, the 4x1 Gefen TV Switcher will switch to that input. Once that device is powered down, the switcher will revert back to the previous input that was active. -
Page 8: Gtv4-Ir Installation
GTV4-IR INSTALLATION Remove battery cover from the back of the GTV4-IR remote. Verify that dip switches 1 & 2 are in the down (OFF) position. Insert the battery, hold the battery so that you can see the positive side facing up. The side that is not marked must be facing down. Test the GTV4-IR remote by pressing ONLY one button at a time. -
Page 9: Ir Code Confi Guration
IR Code channel you wish to use. Press the EQ button to fi nish. Using the guide below, make sure that the unit and remote are both set to the same channel. If this does not work, please call Gefen's tech support for further assistance. -
Page 10: Wiring Diagram
WIRING DIAGRAM... -
Page 11: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ................340 MHz Input Video Signal ................1.2 Volts p-p Input DDC Signal ................. 5 Volts p-p (TTL) Single Link Resolution ..........1080p 12 bit / 1920 x 1200 Input Connector Type ............. HDMI Type A 19 pin Output Connector Type ............
