- Page 1 Multi Format Switcher GTV-MFS User Manual www.gefentv.com...
- Page 3 Chatsworth, CA 91311 www.gefentv.com support@gefen.com Notice Gefen Inc. reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. Multi Format Switcher is a trademark of Gefen Inc. HDMI™ is a trademark of HDMI.org...
-
Page 4: Table Of Contents
TABLE OF CONTENTS Introduction / Operation Notes Features Panel Descriptions Connecting and Operating the Multi Format Switcher RMT-SR-IR Remote Description Multi Format Switcher Configuration / Entering The Menu System / Main Menu / Video Multi Format Switcher Configuration / Video Continued Multi Format Switcher Configuration / Output / Color Multi Format Switcher Configuration / Color Continued / OSD Multi Format Switcher Configuration / OSD Continued / Audio... -
Page 5: Operation Notes
Gefen TV Gefen TV is a unique product line catering to the growing needs for innovative home theater solutions. We specialize in total integration for your home theater, while also focusing on going above and beyond customer expectations to en- sure you get the most from your hardware. - Page 6 FEATURES Features • Both digital and analog inputs are format converted and pixel re-scaled through the Home Theater Scaler Plus. It outputs a large range of formats and resolutions that will easily match the native resolution/ format of your display to ensure highest picture quality. •...
-
Page 7: Panel Descriptions
PANEL DESCRIPTIONS Input LED Power LED Indicator Indicator IR Eye Component Audio Composite Input Input Analog Audio Input S-Video Input Component Input Power HDMI HDMI HDMI Output Input 2 Input 1 SPDIF SPDIF SPDIF 5V DC Power In 2 In 1 Input Optical Optical... -
Page 8: Connecting And Operating The Multi Format Switcher
CONNECTING AND OPERATING THE MULTI FORMAT SWITCHER How to Connect the Multi Format Switcher Connect the HDMI output on the Multi Format Switcher to the display using the supplied HDMI cable. Connect either the digital SPDIF or digital Optical audio output to the display or an external audio processor using user supplied digital audio cables. -
Page 9: Rmt-Sr-Ir Remote Description
RMT-SR-IR REMOTE DESCRIPTION Output - Cycles through the available output resolutions. Please see the section Multi Format Switcher CONFIGURATION / Output on page 8 for the output resolution table. Input - Cycles though all of input sources. The selectable inputs are Composite, S-Video, Component, HDMI 1, and HDMI 2. -
Page 10: Main Menu / Video
MULTI FORMAT SWITCHER CONFIGURATION Entering the Menu System Pressing the Menu button on the included RMT-SR-IR remote control will display the GUI (graphical user interface) for adjustment options. The GUI is overlaid onto the outgoing video to the display. Therefore, the selected source must be outputting a compatible resolution for viewing on the display. - Page 11 MULTI FORMAT SWITCHER CONFIGURATION VIDEO CONTINUED Contrast Adjusts the contrast in increments of 1 on a scale of 1 to 100 (default 50). Brightness Adjusts the brightness in increments of 1 on a scale of to 100 (default 50). Adjusts the hue in increments of 1 on a scale of 1 to 100 (default 50). Saturation Adjusts the saturation in increments of 1 on a scale of 1 to 100 (default 50).
- Page 12 MULTI FORMAT SWITCHER CONFIGURATION V-Pos (Vertical Position) Adjusts the image’s vertical position on the screen. Options: • Adjusts in increments of 1 on a scale of 1 to 100 (default is 50) Y/C Separation - Only for Composite Input Selects the method in which the brightness and color are separated from the composite video signal.
- Page 13 MULTI FORMAT SWITCHER CONFIGURATION COLOR Color Tone Sets the color for the appearance of white. Only the USER option will allow customized settings. The USER settings are saved. Options: • Normal - Normal white color appearance (default) • Warm - Slight red shift to white appearance •...
- Page 14 MULTI FORMAT SWITCHER CONFIGURATION OSD (ON SCREEN DISPLAY) CONTINUED Remote Channel Sets the remote channel for use with the RMT-SR-IR remote control. If the selected channel in this menu and does not match the channel set in the RMT-SR-IR remote, the unit will cease to respond to IR commands from the remote.
- Page 15 MULTI FORMAT SWITCHER CONFIGURATION INFORMATION This menu will allow the user to view general information. There are no configurable options in this menu. • Source - Displays current source • Input - Displays current input source resolution • Output - Displays current output resolution •...
-
Page 16: Rmt-Sr-Ir Installation
These actions will cause the remote to reset and steps 1-4 will have to be repeated. Note: The RMT-SR-IR ships with two batteries. Only one battery is required for operation, the other battery is complimentary. The optional IR extender allows you to relocate your HDMI Switcher and still retain IR control. Gefen part# EXT-RMT-IREXT... -
Page 17: Ir Code Configuration
IR CODE CONFIGURATION How to Resolve IR Code Conflicts In the event that IR commands from other remote controls conflict with the supplied RMT-SR-IR remote control, changing the remote channel will alleviate this issue. The RMT-SR-IR remote control has DIP SWITCHES for configuring the remote channel. -
Page 18: Wiring Diagram
WIRING DIAGRAM... -
Page 19: Specifications
SPECIFICATIONS Digital Video Amplifier Bandwidth ............165 MHz Component Video Bandwidth ..............350 MHz Input DDC Signal ................. 5 Volts p-p (TTL) Input Video Signal ................1.2 Volts p-p Single Link Range ..............1080p/1920 x 1200 Input/Output HDMI Connector ..........Type A 19 pin female Analog Video Connector ............ -
Page 20: Warranty
The information in this manual has been carefully checked and is believed to be accurate. However, Gefen assumes no responsibility for any inaccuracies that may be contained in this manual. In no event will Gefen , be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. - Page 24 Rev X1 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefentv.com support@gefen.com...
