Chapter 2: Jumpers and Connectors

Connector Pin Definitions

External I/O Interfaces

Power LED

Connector location: LED1
PWR
HDD
SYS
GPIO1
Pin Definition
1 CPLD_PWR_LED
3 SW_SYS_LED
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 CPLD_HDD_LED
4 CPLD_GPIO1_LED

PoE LED

Connector location: LED2
POE1
POE2
POE3
POE4
Pin Definition
1 POE_LED1
3 POE_LED3
9
Pin Definition
2 POE_LED2
4 POE_LED4
