Chapter 3: BIOS Setup
Serial Port Console Redirection
This section is used to configure the serial port that will be used for console
redirection.
Aptio Setup - AMI
Advanced
COM0
Console Redirection [Enabled]
► Console Redirection Settings
Legacy Console Redirection
Legacy Console Redirection Settings
►
Serial Port for Out-of-Band Management/
Windows Emergency Managment Services (EMS)
Console Redirection [Enabled]
EMS
Console Redirection Settings
►
Version 2.22.1283. Copyright (C) 2022 AMI
Console Redirection
Enables or disables the console redirection.
Console Redirection Settings
When console redirection is enabled, Console Redirection Settings will be
available.
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
COM0 Console Redirection Settings
Console Redirection
Enable or Disable
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Terminal Type
ANSI
VT100
VT100+ Extends VT100 to support color, function keys, etc.
VT-UTF8 Uses UTF8 encoding to map Unicode characters onto 1 or more
Bits Per Second
Selects the serial port transmission speed. The speed must match the other
side. Long or noisy lines may require a lower speed.
28
Aptio Setup - AMI
Advanced
COM0
Console Redirection Settings
Terminal Type [VT100Plus]
Bits per second [115200]
Data Bits [8]
[None]
Parity
Stop Bits [1]
Flow Control [None]
VT-UTF8 Combo Key [Enabled]
Support
Recorder Mode [Disabled]
Resolution 100x31 [Disabled]
Putty KeyPad [VT100]
Version 2.22.1283. Copyright (C) 2022 AMI
Extended ASCII character set.
ASCII character set.
bytes.
Emulation: ANSI: Extended
ASCII char set. VT100: ASCII
char set. VT100Plus: Extends
VT100 to support color, function
keys, etc.
VT-UTF8: Uses UTF8 encoding
to map Unicode chars onto 1
or more
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
