Chapter 2: Jumpers and Connectors

CPLD JTAG

Connector type: 1x6 6-pin header
Connector location: JTAG1
1 6
Pin Definition
1 P3V3_CPLD
3 JTAG_TCK_CPLD
5 JTAG_TDI_CPLD
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 GND
4 JTAG_TDO_CPLD
6 JTAG_TMS_CPLD

VGA

Connector type: 1x16 16-pin header
Connector location: VGA1
1 16
Pin Definition
1 VGA_VCC
3 NC
5 SMB_BMC_DDC_SDA_R1
7 V_BMC_GFX_REAR_VSYN_R3
9 V_BMC_GFX_REAR_HSYN_R3 10
11 GND
13 GND
15 GND
17
Pin Definition
2 GND
4 SMB_BMC_DDC_SCL_R1
6 NC
8 GND
NC
12 V_BMC_GFX_REAR_BLU_R1
14 V_BMC_GFX_REAR_GRN_R1
16 V_BMC_GFX_REAR_RED_R1
