Chapter 2: Jumpers and Connectors

Internal Power Connector

Connector type: 2x3 6-pin header
Connector location: CN11
6
1
Pin Definition
1 GND
3 GND
5 P12V
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 GND
4 P12V
6 P12V

Power signal to power supply

Connector type: 2x10 20-pin header
Connector location: CN7
2
1
Pin Definition
1 NC
3 NC
5 SMB_PMBUS1_STBY_LVC3_R_SCL
7 SMB_PMBUS1_STBY_LVC3_R_SDA
9 NC
11 PS_ON_R
13 NC
15 PW_OK_A_CAB
17 PW_OK_B_CAB
19 NC
13
20
19
Pin Definition
2 SMB-ALERT_A_CAB
4 SMB-ALERT_B_CAB
6 PRESENT_IN_A_CAB
8 PRESENT_IN_B_CAB
10 GND
12 P3V3_AUX
14 P3V3_AUX
16 GND
18 NC
20 NC
