NISE 3110
User Manual
Version 1.6
February, 2009

Advertisement

Table of Contents
loading

Summary of Contents for Nexcom NISE 3110

  • Page 1 Building the Digital Infrastructure NISE 3110 User Manual Version 1.6 February, 2009...
  • Page 2: Copyright Notice

    (electronic, mechanical, photocopying, This equipment generates, uses, and can radiate radio frequency energy and, recording, or otherwise), without the express written permission of NEXCOM if not installed and used in accordance with the instruction manual, may cause Information provided in this manual is intended to be accurate and reliable.
  • Page 3: Handling Precautions

    Use the correct screws and do not overly tighten them. Keep the original packaging and static-protective bag in case the unit has to be returned. NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 4: Nexcom Rma Policy

    Customers shall enclose the “NEXCOM RMA Service Form” with the returned packages. Items will be replaced with NEXCOM products if the original one is not able to be repaired. Ex: motherboard, power supply, etc. Customers must collect all the information about the problems encountered and note anything abnormal or, print out any on-screen messages, and Replaced with 3rd party products if needed.
  • Page 5: Global Service Contact Information

    Europe NEXCOM UK 10 Vincent Avenue, Crownhill Milton Keynew, Buckinghamshire MK8 0AB, United Kingdom Tel: 44-(0)-1908-21 88 77 Fax: 44-(0)-1908-21 88 67 Email: sales@nexcomuk.co.uk Website: www.nexcomuk.co.uk Japan NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 6: Rohs Compliance

    Feb.,08 Correct P28 GPIO pin definition (J11) green products. The task force will ensure that we follow the standard NEXCOM March, 08 Add the Appendix E: Display Setting development procedure and that all the new RoHS components and new...
  • Page 7 Warranty and RMA NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 8: Table Of Contents

    Acknowledgements ..................2 Figure 1.3: Dimension drawing of EBC 576 ..........15 Declaration of Conformity ................2 Figure 1.4 Dimension drawing of NISE 3110 ..........16 Installation Suggestions ................. 2 Chapter 2 Jumper Setting ..........17 Handling Precautions ..................3 2.1 Setting Jumpers...
  • Page 9 5.Open Bottom Cover ................... 44 6.Install HDD ....................45 7.Close Bottom Cover................... 45 Appendix E-Display Seting ..........46 Appendix F-IEGD Installation Guide ........48 Appendix G-Award BIOS Setup ......... 51 NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 10: Chapter 1 General Information

    Chapter 1 General Information NISE 3110 Fan-less BOX Computer...
  • Page 11: Product Overview

    945GME DDR2 Slot DDR2 Channel B DVI Chrontel For data storage, the NISE 3110 provides one CompactFlash socket and one 2.5" 1 x PCIe 4 Lanes 2GB/s Interface HDD drive bay. The System supports ATX mode power feature and can accept a...
  • Page 12: Specifications

    1 x On-board CompactFlash socket 240 mm (When no HDD is installed) 1 x Internal 2.5" HDD drive bay NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 13: Ordering Information

    -10°C to 55°C (W/CF card only) Storage temperature: -20°C to 80°C Relative humidity: 10% to 90% (Non-condensing) Certifications CE approval NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 14: Board Layout

    Chapter 1 General Information 1.6 Board Layout Figure 1.2 Top View of the EBC 576 NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 15: Dimension Drawing

    Chapter 1 General Information 1.7 Dimension Drawing Figure 1.3: Dimension drawing of EBC 576 NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 16 Chapter 1 General Information Figure 1.4 Dimension drawing of NISE 3110 NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 17: Chapter 2 Jumper Setting

    Chapter 2 Jumper Setting NISE 3110 Fan-less BOX Computer...
  • Page 18: Setting Jumpers

    OPEN. These illustrations show a 3-pin Jumper. Pins 1 and 2 are SHORT. Table 2.1 Setting Jumpers NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 19: Location Of Jumpers

    ATX Switch LVDS (CN3) (SW1) ATX Remote Switch (JP12) DVI(CN1) CCFL(J4) Figure 2-1: Jumper Location of EBC 576 NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 20: Definition Of Jumpers

    <1-2 pin short= Master / **2-3 pin short= Slave> VCC3 Def. Def. Def. Slave (GND) CF_CSEL Master (VCC5) NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 21 <1-2 short: RI Power = 5v / 3-4 short: RI Power=12V / **4-5 short: Normal > PIN Def. Def. Def. Def. Def. SP_RI4 +12V 2 VCC5 NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 22 Pin. Def. +12V SENSE FAN_CTRL J1/J2: SYSTEM FAN ( 1x 3 pin Wafer, 2.54mm) Pin. Def. SENSE NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 23 DVI_DATA1 LA_DATAP1 CAS_GND CAS_GND Pin. Def. Pin. Def. DVI_VCC CAS_GND DDCCLK LB_CLK_P CAS_GND DDC_DATA LB_DATAN1 LB_CLK_N LB_DATAP0 NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 24 Connector capacitance 10pf to Ground Device Select# Device Select# Lock# Lock# Clock1 Grant#1 Parity Error# Parity Error# Reset# NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 25 Address and Data 3 Address and Data 3 SLCT Address and Data 1 Address and Data 1 NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 26 Ground CF_CD2# CF_CD1# Ground RXP0 SDD11A SDD12A SDVO_CTRLCLK RXN0 SDD13A SDD14A Ground Ground SDD15A SDCS#3 SDIOR# SDIOW# NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 27 Def. Pin. Def. DD10 RED_VGA VGA_VCC DD11 GREEN_VGA DD12 BLUE_VGA DD13 DATA_V DD14 HS_VGA DD15 VS_VGA CLK_V NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 28 +12V Brightness Ctrl GP21: Output GP25: Input GP22: Output GP26: Input Backlight Enable GP23: Output GP27: Input NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 29 TXP1 TXN1 CON1-B: RXN1 TX0P_E VCC3 RXP1 TX0N_E LINK_E TX1P_E TX2P_E TX2N_E TX1N_E TX3P_E TX3N_E ACT_E LINK_E NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 30 RTS3 CTS3 Def. Def. GreenUpper Line-Out Pink Lower MIC-In COM4 (RS-232) labelled “D“ on DB9 cable connector NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 31 DB9 Pin# Def. TXD- TXD+ RXD- RXD+ Pin. Def. Reserved Reserved Reserved Reserved PWR_ON Reserved Reserved Reserved Reserved NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 32 Chapter 2 Jumper Setting USB1: USB Port (Dual USB port) Pin. Def. Pin. Def. USB_1N USB_0N USB_1P USB_0P NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 33: Appendix A-Watchdog Timer

    Appendix A-Watchdog Timer NISE 3110 Fan-less BOX Computer...
  • Page 34: Watchdog Timer Common Library

    2eh,al al,55h 2eh,al 2eh,al al,07h 2eh,al al,07h 2fh,al SetupWDT ENDP =============================================================== InitWDT PROC al,71h 2eh,al al,30h 2fh,al NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 35 Set 5 sec. (time out vale: 0x00-0xff) 2fh,al SetWDTTime ENDP =============================================================== ExitSetup PROC al,02h 2eh,al al,02h 2fh,al ExitSetup ENDP NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 36: Appendix B-Gpio Programming Guide

    Appendix B-GPIO Programming Guide NISE 3110 Fan-less BOX Computer...
  • Page 37 GPIO Pin-20 signal level is controlled by BIOS, high defined as system power up and low defined as system shutdown with standby power. NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 38: Appendix C-Power Consumption

    Appendix C-Power Consumption NISE 3110 Fan-less BOX Computer...
  • Page 39 Full loading mode should utilize CPU 100% with run Burn-in test program. Idle mode will utilize CPU loading below 5%, and there is no data or application running. NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 40: Appendix D-Installation Guide

    Appendix D- Installstion Guide NISE 3110 Fan-less BOX Computer...
  • Page 41: Handling Precautions

    2-pin Phoenix power connector x1 CD Driver x 1 120W Power Adapter x 1 IDE cable x 1 NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 42: Installation

    Step 2-1: Unscrew 6 screws on heat sink Step 1-1: Remove 6 screws from the top. Step 2-2: Pay attentions to CPU installation NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 43 Step 2.6: Lock the heat sink Step 2.4: Secure the CPU NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 44: Install/Remove Ram Module

    Step 3-1: Insert either 1 or 2 DDR 4.Close Top Cover Step 4-1: Secure the top cover with screws NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 45: Install Hdd

    SATA cable at the right position. 7.Close Bottom Cover Step 6-2: Secure 2.5” HDD Step7-1: Lock bottom cover with screws NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 46: Appendix E-Display Seting

    Appendix E- Display Setting NISE 3110 Fan-less BOX Computer...
  • Page 47 Have NISE system linked with VGA/DVI monitor Select "Intel GMA Driver for Mobile" from Control Panel Select "Enable Hot Keys" from Hot Keys NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 48: Appendix F-Iegd Installation Guide

    Appendix F- IEGD Installation Guide NISE 3110 Fan-less BOX Computer...
  • Page 49 Step 1: Remove original graphic driver under Windows XP or Windows XPe. Step 2: After reboot, please set “Boot Display” to be “CRT+DVI” in BIOS set- ting. NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 50 Step-5: Press “Advanced” in Display Properties. 945_DVI (single) 945_CRT (single) 945_DVI, 945_CRT (twin) 945_DVI (clone) 945_CRT 945_DVI (extend) 945_CRT NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 51: Appendix G-Award Bios Setup

    Appendix G- Award BIOS Setup NISE 3110 Fan-less BOX Computer...
  • Page 52 Detecting configuration error by the system and you are prompted to make changes to modification in the future. User can download any major updated items or reversion from the Setup program NEXCOM web site http://www.nexcom.com.tw. If any unclear message occurs, please • Resetting the system clock contact NEXCOM customer service representative for help or log onto •...
  • Page 53 Use this menu to specify your settings for integrated peripherals. Power Management Setup Use this menu to specify your settings for power management. PnP/PCI Configurations NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 54 (only for Option Page Setup The table below lists the keys that help you navigate the setup Menu) program. NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 55 Figure 7-1: BIOS – Standard CMOS Features The Standard CMOS Setup utility is used to configure the following features: NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 56 Figure 7-2: IDE channel setting Figure 7-4: IDE channel setting Figure 7-3: IDE channel setting Figure 7-5: IDE channel setting NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 57 The system will boot, but access to Setup will be denied if the correct pass- word is not entered at setup. NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 58 Features setup, press <ESC> to go back to the main screen. The options are 640x480 18bits, 800x600 18bis, 1024x768 18bits. Figure 9-2: On chip IDE Device NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 59 378h and IRQ of 7 should work well in most cases. Unless you have a prob- lem with the parallel port, you should leave it at the default settings. The choices: 378/ NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 60 PnP (Plug and Play) NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 61 Card and the system reconfiguration has caused such a serious conflict that the operating system can not boot. The choices are Enabled and Disabled. NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
  • Page 62 Selecting this option and pressing <Enter> will save the new setting information in the CMOS memory and continue with the booting process. NISE3110 User Manual Copyright © 2006 NEXCOM International Co., LTD. All rights reserved Copyright © 2006 NEXCOM International Co., LTD. All rights reserved...
