Chapter 2: Jumpers and Connectors
Internal Connectors
PoE Header
Connector type: 2x12 24-pin header
Connector location: POE1
2
1
Pin
Definition
1
POE_LED1
3
POE_LED3
5
GND
7
SMB_DAT_POE_R
9
SMB_CLK_POE_R
11
GND
13
POE MAIN POK
15
P54V
17
P54V
19
P54V
21
VPORT_NEG_10G_OUT8
23
VPORT_NEG_10G_OUT7
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
24
23
Pin
Definition
2
POE_LED2
4
POE_LED4
6
P3V3
8
POE_INT_N
10
POE_RST_N
12
NC
14
VPORT_NEG_10G_OUT4
16
VPORT_NEG_10G_OUT3
18
VPORT_NEG_10G_OUT2
20
VPORT_NEG_10G_OUT1
22
VPORT_NEG_10G_OUT5
24
VPORT_NEG_10G_OUT6
PWM Controller SMBUS Header
Connector type: 1x3 3-pin header
Connector location: JP4
1
3
Pin
Function
1
SMB_DATA
2
SMB_CLK
3
GND
10
FTA5180 Series User Manual
