Chapter 2: Jumpers and Connectors

Connector Pin Definitions

External I/O Interfaces

12V DC Input

Connector location: CN1
Pin
Definition
1
GND
2
GND
3
P12V_IN
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.

System Reset Button

Connector location: SW2
Pin
Definition
1
GND
2
RESET_BUTTON
3
GND
9
DTA1376 Series User Manual
