Nexcom FTA 5180 Series User Manual page 63

Chapter 3: BIOS Setup
BMC Network Configuration Cont.
Aptio Setup - AMI
*********************
Lan channel 1
IPv6 Support [Enabled]
Configuration Address [Unspecified]
source
Current configuration DynamicAddressBmcDhcp
Address source
Station IPv6 address
::
Prefix Length
0
IPv6 address status Active
IPv6 DHCP Algorithm DHCPv6
Version 2.22.1283. Copyright (C) 2022 AMI
IPv6 Support (LAN Channel 1)
Enables or disables IPv6 support for LAN channel 1.
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Server Mgmt
Select to configure LAN
channel parameters
statiscally or
dynamically (by BIOS or
BMC). Unspecified
option will not modify
any BMC network
parameters during BIOS
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
50
Aptio Setup - AMI
Configuration Router [Unspecified]
Lan1 Address source
Current Router DynamicAddressBmcDhcp
Configuration Address
source
IPv6 Router IP Address
::
IPv6 Router Prefix Length
255
IPv6 Router Prefix Value
::
******************
Version 2.22.1283. Copyright (C) 2022 AMI
Server Mgmt
Select to configure LAN
channel parameters
statiscally or
dynamically (by BIOS or
BMC). Unspecified
option will not modify
any BMC network
parameters during BIOS
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
