Chapter 2: Jumpers and Connectors
Connector Pin Definitions
External Connectors
12V DC Power Input
Connector location: CN7
Pin
Definition
1
GND
2
GND
3
P12V
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
Power Button
Connector location: SW1
Pin
Definition
1
PWR_BTN_CAL_N
3
GND
A1
PWRON_R
MH1
GND
9
Pin
Definition
2
GND
4
PWR_BTN_CAL_N
C1
PWRON_R2
MH2
GND
DNA 130 User Manual
