Chapter 3: BIOS Setup
Trusted Computing
This section is used to configure Trusted Platform Module (TPM) settings.
Aptio Setup - AMI
Advanced
TPM 2.0 Device Found
Firmware Version: 7.62
Vendor: IFX
Security Device [Enable]
Support
Active PCR banks SHA-1, SHA256
Available PCR banks SHA-1, SHA256
SHA-1 PCR Bank [Enabled]
SHA256 PCR Bank [Enabled]
Pending operation [None]
Platform Hierarchy [Enabled]
Storage Hierarchy [Enabled]
Endorsement [Enabled]
Herarchy
TPM2.0 UEFI Spec [TCG_2]
Version
Physical Presence [1.3]
Spec Version
TPM 2.0 [TIS]
Version 2.22.1283. Copyright (C) 2022 AMI
Security Device Support
Enables or disables BIOS support for security device. O.S will not show
Security Device. TCG EFI protocol and INT1A interface will not be available.
SHA-1 PCR Bank
Enables or disables SHA-1 PCR Bank.
SHA256 PCR Bank
Enables or disables SHA256 PCR Bank
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Pending operation
Schedules an operation for the security device.
Platform Hierarchy
Enables or disables Platform Hierarchy.
TPM 1.2 will restrict support
Storage Hierarchy
to TPM 1.2 devices, TPM 2.0
will restrict support to TPM 2.0
Enables or disables Storage Hierarchy.
devices, Auto will support both
with the default set to TPM 2.0
devices if not found,
Endorsement Hierarchy
Enables or disables Endorsement Hierarchy.
TPM2.0 UEFI Spec Version
Configures the TPM2.0 UEFI spec version.
→←: Select Screen
↑↓: Select Item
Enter: Select
Physical Presence Spec Version
+/-: Change Opt.
F1: General Help
Configures the physical presence spec version.
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Device Select
ESC: Exit
TPM 1.2 will restrict support to TPM 1.2 devices. TPM 2.0 will restrict support
to TPM 2.0 devices. Auto will support both TPM 1.2 and 2.0 devices with
the default set to TPM 2.0 devices if not found, and TPM 1.2 devices will be
enumerated.
