Chapter 2: Jumpers and Connectors

Connector Pin Definitions

External I/O Interfaces

HDMI Port

Connector type: Phone Jack single port, 6P, pink
Connector location: CN1
Pin Definition
1 MIC_R
3 AGND
5 AGND
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 MIC_JD
4 LOUT_L
6 AGND
External I/O Interfaces
HDMI Port
Connector type: Phone Jack single port, 6P, green
Connector location: CN2
Pin Definition
1 LOUT_R
3 AGND
5 AGND
12
Pin Definition
2 LOUT_JD
4 LOUT_L
6 AGND
