Chapter 3: BIOS Setup
Port 1A
Aptio Setup - AMI
Port 1A
---------------------------------------------------------------------------------
------
PCI-E Port
[Auto]
[Auto]
Link Speed
[-3.5 dB]
PCI-E Port DeEmphasis
PCI-E Port Link Status
Link Did Not Train
PCI-E Port Link Max
Max Width x8
Link Did Not Train
PCI-E Port Link Speed
PCI-E Port MPSS
[Auto]
Version 2.22.1283. Copyright (C) 2022 AMI
PCI-E Port
Enables or disables the PCIe port. In auto mode the BIOS will remove the
EXP port if there is no device or errors on that device and the device is not
HP capable. Disable is used to disable the port and hide its CFG space.
Link Speed
Configures the link speed for the PCIe port.
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Socket Configuration
In auto mode the BIOS
will remove the EXP
port if there is no
device or errors on
that device and the
device is not HP
capable.
Enable/Disable is used
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
PCI-E Port DeEmphasis
Configures the de-emphasis control for the PCIe port.
PCI-E Port MPSS
Configures the PCI-e Port MPSS.
43
FTA5180 Series User Manual
