System overview
The VESA bracket is installed on IP54 VESA mounting units (5ACCMA00.0100-000 and 5ACCMA00.0101-000).
If a VESA bracket is selected as the mounting system, as with the mounting unit mentioned above, VESA 100 or
VESA 75 installation is possible.

3.3.4 Flanges

A flange is installed on the mounting unit and establishes the connection between the Automation Panel or Panel
PC and the swing arm system.

3.3.5 Expansion units

Expansion units can be installed on AP5230 panels with expansion option. It is possible to choose between an
expansion cover and an expansion unit.
Expansion covers have cutouts that can be used to install the desired operating elements at a later time.
The operating elements are already integrated in expansion units.

3.3.6 Handles

Handles can be installed on the sides of the panel to enable comfortable, ergonomic operation.
Automation Panel 5000 User's manual V2.11 17
