Technical data
Model number
Display
Type
Diagonal
Colors
Resolution
Contrast
Viewing angles
Horizontal
Vertical
Backlight
Type
Brightness (dimmable)
Half-brightness time
1)
Touch screen
Type
Technology
Controller
Transmittance
Operating conditions
Pollution degree per EN 61131-2
Degree of protection per EN 60529
Degree of protection per UL 50
Mechanical properties
Housing
Material
Coating
Front
Frame
Design
Dimensions
Width
Height
Weight
1) At 25°C ambient temperature. Reducing the brightness by 50% can increase the half-brightness time by approximately 50%.
4.2.1.9.4 Dimensions
86
IP65 with mounting unit 5ACCMA00.000x-000
IP54 with mounting unit 5ACCMA00.010x-000
Type 4X indoor with mounting unit 5ACCMA00.000x-000
Type 1 with mounting unit 5ACCMA00.010x-000
Table 20: 5AP5230.156B-000 - Technical data
433
Figure 22: 5AP5230.156B-000 - Dimensions
5AP5230.156B-000
TFT color
15.6"
16.7 million
HD, 1366 x 768 pixels
1000:1
Direction R = 85° / Direction L = 85°
Direction U = 85° / Direction D = 85°
LED
Typ. 40 to 400 cd/m²
70,000 h
3M
Projected capacitive touch (PCT)
3M
>90%
Pollution degree 2
Aluminum, coated
White aluminum (similar to RAL 9006)
Aluminum (similar to RAL 9006), coated
Black
433 mm
349 mm
6400 g
