Model number
Operating conditions
Pollution degree per EN 61131-2
Mechanical properties
Material
Dimensions
Height
Diameter
Weight
Danger!
+24 VDC power supply
The swivel-tilt flange is only permitted to be used in conjunction with devices supplied with a SELV/
PELV power supply or with safety extra-low voltage (SELV) per EN 60950.
4.2.4.2.4 Dimensions
Automation Panel 5000 User's manual V2.11
Table 54: 5ACCFL00.0100-000 - Technical data
Figure 37: 5ACCFL00.0100-000 - Dimensions
5ACCFL00.0100-000
Pollution degree 2
Anodized aluminum E6/C0
147 mm
90 mm
1666 g
Technical data
125
