Installation and wiring
7. If required, wire the operating elements.
For information about wiring operating elements on the expansion unit, see section
on page 65.
For information about wiring or installing operating elements on the expansion cover, see section
operating elements on the expansion cover" on page
8. Install the back cover with the 14 Torx screws (T20). The tightening torque for each is 2.3 Nm.
Information about impermeability
Warning!
Failure to follow instructions can result in damage to property.
• The gasket must be inspected before installation or reinstallation and at regular intervals according to the
requirements of the operating environment.
• Replace the entire device if inspection reveals visible scratches, cracks, dirt deposits or excessive wear.
• Do not stretch the gasket unnecessarily.
• Avoid contact between the gasket and the corners and edges of the frame.
• It is important to ensure that the gasket is completely inserted into the installation notch.
• The housing components must be secured using the specified tightening torque.
