Model number
Diagonal
Colors
Resolution
Contrast
Viewing angles
Horizontal
Vertical
Backlight
Type
Brightness (dimmable)
Half-brightness time
1)
Touch screen
Type
Technology
Controller
Transmittance
Operating conditions
Pollution degree per EN 61131-2
Degree of protection per EN 60529
Degree of protection per UL 50
Mechanical properties
Housing
Material
Coating
Front
Frame
Design
Dimensions
Width
Height
Weight
1) At 25°C ambient temperature. Reducing the brightness by 50% can increase the half-brightness time by approximately 50%.
4.2.1.14.4 Dimensions
Automation Panel 5000 User's manual V2.11
IP65 with mounting unit 5ACCMA00.000x-000
IP54 with mounting unit 5ACCMA00.010x-000
Type 4X indoor with mounting unit 5ACCMA00.000x-000
Type 1 with mounting unit 5ACCMA00.010x-000
Table 30: 5AP5230.215I-000 - Technical data
352
Figure 32: 5AP5230.215I-000 - Dimensions
5AP5230.215I-000
21.5"
16.7 million
FHD, 1920 × 1080 pixels
5000:1
Direction R = 89° / Direction L = 89°
Direction U = 89° / Direction D = 89°
LED
Typ. 12.5 to 250 cd/m²
30,000 h
3M
Projected capacitive touch (PCT)
3M
>90%
Pollution degree 2
Aluminum, coated
White aluminum (similar to RAL 9006)
Aluminum (similar to RAL 9006), coated
Black
352 mm
632 mm
5400 g
Technical data
101
