Model number
Nominal current
Overvoltage category per EN 61131-2
Galvanic isolation
Operating conditions
Pollution degree per EN 61131-2
Mechanical properties
Dimensions
Width
Height
Depth
Weight
1)
EN 60950 requirements must be observed; see section "+24 VDC power supply" of the data sheet.
Automation Panel 5000 User's manual V2.11
Table 34: 5DLSD4.1001-00 - Technical data
5DLSD4.1001-00
Max. 3 A
II
Yes
Pollution degree 2
190 mm
110 mm
23.6 mm
525 g
Technical data
107
