Appendix D
D.9.3.2 Switching element RAFIX 22 FS+ "Plus 1", 1.20.126.514/0000
Manufacturer
Type
Manufacturer number
Quantity
Contact system
Contacts
Normally closed contact with positive
separation per IEC 60947-5-1
Connection
Service life (switching cycles)
B10 value (switching cycles)
Min. AC/DC operating voltage
Max. AC/DC operating voltage
Min. AC/DC operating current
Max. AC/DC operating current
Max. switching capacity
D.9.4 5ACCSE00.0002-000
General information
• 1x key switch
• 1x switching element
D.9.4.1 Key switch RAFIX 22 FS+, 1.30.255.432/0000
Manufacturer
Type
Manufacturer number
Quantity
Contact function
Number of possible closings
Angle of rotation
Key removal position
Service life
B10 value
D.9.4.1.1 Replacement key for key switch RAFIX 22 FS+ 5.58.007.001/0000
ROHS-compliant
REACH-compliant
D.9.4.2 Switching element RAFIX 22 FS, 1.20.126.105/9000
Manufacturer
Type
Manufacturer number
Quantity
Contact system
Contacts
208
Switching element 1.20.126.514/0000
RAFI
RAFIX 22 FS+ "Plus 1"
1.20.126.514/0000
1
Self-cleaning bridge contact
2 normally closed contact + 1 normally open contact
Yes
Connector 2.8x0.8 mm
50,000 at 10 mA / 24 VDC
65,000
5 V
42 V
1 mA
100 mA
250 mW
Table 102: Switching element 1.20.126.514/0000
Key switch 1.30.255.432/0000
RAFI
RAFIX 22 FS+
1.30.255.432/0000
1
Maintained
500
2x 90°
0+1+2
50,000 maintained / 30,000 key removal switching cycles
65,000 maintained / 40,000 key removal switching cycles
Table 103: Key switch 1.30.255.432/0000
Replacement key 5.58.007.001/0000
Yes
Yes
Switching element 1.20.126.105/9000
RAFI
RAFIX 22 FS
1.20.126.105/9000
1
Self-cleaning bridge contact
2 normally open contacts
Table 104: Switching element 1.20.126.105/9000
Example image
Example image
Example image
Example image
