7.9.7.1 Connecting the optional EMS 1000 (EnviroProbe)
1. You can connect a maximum of 16 optional EMS 1000 (EnviroProbe) devices to each
UPS to expand the environment monitoring range. A maximum of 8 UPS units can
be paralleled. Please use the CAT-5 cable (user-supplied & the cable length depends
on the on-site application and environment) to connect the EMS 1000 (EnviroProbe)
to the EMS port on the UPS. For the location of the EMS port, please refer to
about installation of the optional EMS 1000 (EnviroProbe), please refer to
2. The UPS only supports RS485 communication mode. When installing the EMS 1000
(EnviroProbe), please set the device's communication mode as RS485 following
to the UPS for the UPS to identify different devices. When installing the EMS 1000
(EnviroProbe), please set the ID # by the four ID DIP switches on the left of the device
following
4. To enable the EMS function of the UPS, you have to set up relevant items on the LCD
after connecting the optional EMS 1000 (EnviroProbe) to the UPS. Please refer to
7.10 UPS Settings
7.10.1 Bypass Setting
Path:

SETUP

After entering the BYPASS SETTING screen*
the Bypass Frequency Range, Bypass Voltage (Max.), Bypass Voltage (Min.) and ECO
Voltage Range. If any value is out of range, the system will issue an alarm. These settings
for assistance.
Modulon DPH Series
.
NOTE:
1. You must set the ID # on the LCD according to the ID DIP switch setting on
the EMS 1000 (EnviroProbe) device. Please refer to
2. The ID # of each EMS 1000 (EnviroProbe) device connected to the UPS
3. When connecting more than one EMS 1000 (EnviroProbe) devices to the
UPS, you don't have to set the ID # in numerical order.
.
1
NOTE:
* means that the Administrator password is needed. For password
information, please refer to
of the
of the
1
7-30
; for more information
.
.
.
.
