5.7.3 STS Module's LED Indicator
The STS module's LED indicator shows its operation status. Please refer to the following
table.
LED Indicator
OFF
ON (yellow)
Flashing (yellow)_ on for 0.3
NOTE:
In bypass mode, if you turn the STS module's switch to the lower position (
LED Indicator
The STS module is OFF.
The STS module is working in bypass mode,
ECO mode, or energy recycle mode.
The STS module is abnormal.
5-41
5
Installation and Wiring
Description
), the
