2.5 Front View
On the front of the UPS, there are a 10" color touch panel, a tri-color LED indicator, a door
switch, six casters and four leveling feet. Please see
Touch Panel
1. For information about the 10" color touch panel, please refer to
2. For information about the tri-color LED indicator, please refer to
3. The casters at the bottom of the UPS can be used to move over short distances, and
the leveling feet fix and stabilize the UPS on the ground. Please refer to
4. Please refer to
10" Color
Casters
.
.
for relevant information.
for how to open the UPS front door.
Leveling Feet
2-7
2 Introduction
.
Tri-color LED
Indicator
Door Handle
