After 20 seconds of LCD initialization, the LCD will enter the Main Screen. For the
Main Screen information, please refer to
Now, each power module keeps running and its LED indicator remains green. After
each power module finishes establishing DC BUS voltage, the charger will start to
charge the batteries.
If the bypass AC source is within the normal range, the UPS will transfer to run in
Bypass mode, the LCD screen will show as
will illuminate yellow.
