Battery Type
Battery Rating Voltage
Battery Strings
Battery Low Warning

Float Charge Voltage

Equalized Charge
Restored Voltage

Charge Current (Max)

Auto Equalized Charge

Auto Equalized Charge

Equalized Charge Time

Battery Test Fail Voltage

Modulon DPH Series
Item
Set up the battery rating voltage.
Set up how many battery strings that are used on site.
Set up the battery low warning voltage.
Set up the battery low voltage. In Battery mode, when the
battery low voltage is reached, the battery power will be cut
then be transferred to bypass if the bypass is available;
otherwise, the UPS will shut down.
Capacity Set up the battery capacity.
Set up the equalized charge voltage.
Voltage
Set up the restored voltage.
Set up the maximum charge current.
Enable or disable the auto-equalized charge.
Set up the auto equalized charge interval.
Interval
Set up the equalized charge time.
Set up the battery test fail voltage. When the battery
voltage is under the test fail voltage, it means battery fail.
Description
2
2. * If you use the Delta lithium-ion batteries,
please set up the battery type as 'LiB
(Integration)'. The item 'LiB (Integration)'
will only appear on the LCD if you use the
Delta lithium-ion batteries with the optional
multifunctional communication card (MFC)
being installed in the smart slot shown in
. Please contact Delta customer
service if you need more information.
NOTE:
The item will only show up if the Battery
Type is set as ' VRLA'.
NOTE:
1. The item will only show up if the Battery Type
is set as 'LiB (Integration)'. When the
remaining battery voltage reaches the setup
restored voltage, the UPS will automatically
activate the charger to re-charge the batteries.
2. If the Battery Type is set as 'LiB (Dry Contact)',
the item will not show up.
7-36
