4
Insert the power module into the unoccupied power module slot until it snaps into
place. Two people are required.
Modulon DPH Series
NOTE:
Please install the power modules from the top layer of the power module slot
to the bottom layer of the power module slot in sequence.
A GND B A
GND B
RESET BMS
MODBUS
(UPS Front View with Door Open)
DISPLAY
EXT. BATT
BT1 BT2 TEMP. EXT.SWITCH STATUS O/P DRY
S1 S2 P1 CONTACT CONTACT I/P DRY
P2 P3 P1 P2
REPO
NC NO
PARALLEL
BT3 BT4
S3 S4 P4 P5
P6 P3 P4
BATT. START
PARALLEL PARALLEL
USB
RS-232 BATT.
START
INP UT BRE
AKE R
OU TPU
T BRE AKE
R
BYP ASS
BRE AKE
R
MA NU AL
BYP ASS
BRE AKE
R
5-44
Power Module
