Delta Modulon DPH Series User Manual page 91

(Rear View after
Rear Panel Removal)
2
For top wiring, remove the three top covers (2 screws for each cover); for bottom
wiring, remove the three bottom covers (2 nuts for each cover). See
for the location of the top and bottom covers.
Top Cover × 3
(Each with
Two Screws)
Bottom Cover × 3
(Each with
Two Nuts)
PE ( ) & GND ( )
Terminals for Top Wiring
AC
INPUT
L 1
BYPA SS
INPUT
PE ( ) & GND ( )
Terminals for Bottom Wiring
Rear Panel Removal)
BAT TER Y
INP UT
UP S
T
OU TPU
5-15
5 Installation and Wiring
(Rear View after
AC
INP
BYP
INPU
