NOTE:
1
1. *
means that the Administrator password is needed. For password information, please
refer to
2
2. *
means that the item will only appear on the LCD if you use the Delta lithium-ion
batteries with the optional multifunctional communication card (MFC) being installed in
the smart slot shown in
more information.
3. The information on the LCD screen presented in
the UPS operation mode, machine number, date, time, total number of alarms, load
(%), battery remaining time, user login or administrator login, are for reference only. The
actual screen of display depends on the operation situation.
4. To turn on the touch panel, please refer to
5. (1) The setting of the
Button (
(2) If you want to change the access setting for the ON/ OFF Button (
go to
information, please refer to
7.2
How to Turn on the LCD
To turn on the LCD, please follow the steps below:
1
Perform one of the options (a.~d.) below; after that, the LCD will be on and the LCD
initial screen will appear.
a. Turn on the Input Breaker (Q1); or
b. Turn on the Bypass Breaker (Q2); or
c. Turn on the Input Breaker (Q1) and Bypass Breaker (Q2); or
d. Turn on the external battery cabinet's breaker (Q5), open the front door of the
UPS, and press any of the battery start buttons (
release it.
.
.
) presented in this user manual.
General Setting
SETUP
. Please contact Delta customer service if you need
is set as 'Any User' for all the ON/ OFF
User
On/ Off Button Access. For relevant
.
7-3
7
LCD Display & Settings
, including
and
), please
) for 1 second and
