3

Mechanical Layout

3.1

Connector Locations

3.1.1 Rear I/O Connectors
3.1.2 Component-Side Connectors
ATX Power
Connector
Mini PCIe
LVDS Inverter
Power Connector
LVDS
Case Open
Debug Header
4x COM
8-bit GPIO
USB 3.1 Gen 1
USB 2.0 Header
4x/2x SATA
Connectors
SPI Header
ATX 12V Power
Connector
Mechanical Layout
DP
LAN
HDMI
USB 3.1 Gen 1/2

Figure 2: AmITX-CF-I Rear I/O

COM
Line In
DVI
MIC In
AmITX-CF-I
Line Out
2x DDR4 SODIMM
PCIe x16
Front Panel
Header
CPU Fan
System Fan
Audio Header
9
