Technical Data

13 Technical Data
13.1

Technical Specifications

Article identification
Communication connector
Configuration connector
Serial connector
Power connector
Power supply
Power consumption
Storage temperature
Operating temperature
Humidity
Vibration
Housing material
Protection class
Product weight
Dimensions
Mounting
Additional technical data and information related to the installation and use of this product can
be found at www.anybus.com/support.
® ™
Anybus Communicator User Manual
ABC3007-A
RJ45 x 2
RJ45
7-pin screw connector
3-pin screw connector
12-30 VDC
Reverse voltage protection and short circuit protection
Typical: 160 mA @ 24 V
Max: 400 mA @ 12 V
-40 to +85 °C
-25 to +70 °C
EN 600068-2-78: Damp heat, +40°C, 93% humidity for 4 days
EN 60068-2-30: Damp heat, +25°C – +55°C, 95% RH, 2 cycles
See datasheet
Plastic
See datasheet for details
IP20
150 g
27 x 144 x 98 mm (H x W x D) with connectors included
DIN-rail
119 (124)
