Communicator Configuration
7.9.4 To Configure IP Settings Manually
1. Deselect the DHCP enabled checkbox.
2. Configure the IP settings.
Setting
IP address
Subnet mask
Gateway address
Primary DNS
Secondary DNS
If you change a value and click Refresh, the value is reset to the last applied value.
3. To apply the settings, click Apply IP Settings.
7.9.5 Naming the Host
You can label the Communicator.
• The maximum allowed length of the Hostname is 64 characters.
• No symbol characters, punctuation characters, or whitespace are permitted.
• Write the Hostname as one single word.
® ™
Anybus Communicator User Manual
Description
The EtherNet/IP network IP address in IPv4 dot-decimal notation
The EtherNet/IP network Subnet mask in IPv4 dot-decimal notation.
TheEtherNet/IP network Gateway address in IPv4 dot-decimal notation.
If there is no gateway available, set the Gateway address to: 0.0.0.0
The EtherNet/IP network Primary DNS in IPv4 dot-decimal notation.
The EtherNet/IP network Secondary DNS in IPv4 dot-decimal notation.
