Installation
5.6

Security Switch

After completing the configuration of the Communicator, lock the security switch to prevent
unauthorized access to the Communicator built-in web interface.
When the security switch is in its locked position, the Communicator built-in web interface can
not be accessed and the Communicator can not be configured. Network specific parameters,
configured via the PLC is still available.
To Lock and Unlock the Security Switch
Use a pointed object, such as a ballpoint pen.
• To lock the security switch, push the toggle towards the Communicator front.
• To unlock the security switch, push the toggle towards the Communicator back.
Security Switch Status LED
When the security switch is in its:
• locked position, the security switch status LED turn solid green.
• unlocked position, the security switch status LED is turned off.
® ™
